CENTRIC 320.61023F Part Description
Manufacturer
Product Description
Centric GCX Rotor with Full Coating
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron Formulation Enhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
- For the best corrosion resistance
- RS200™ Zinc-Aluminum Rich Coating
- Optimal Surface Finish
- For consistent and confident braking from the first stop
- Carbon Enhanved Advanced Metallurgy
- For optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- For heat capacity and strength
- Low Initial Lateral Run-Out
- For smooth vibration free stopping
- Precision Balance
- For vibration free performance
CENTRIC 320.61023F Specifications
Product Attributes
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 0 |
| Product Grade [cntrc] | Premium |
| Weight [cntrc] Kgs | 4.770 |
| Weight [cntrc] Lbs | 10.500 |
| Disc Mounting [cntrc] | Floating |
| Vane Style [cntrc] | Curved |
| Discard Thickness | 0.896 IN |
| Discard Thickness | 22.750 MM |
| Nominal Thickness | 24.000 MM |
| Nominal Thickness | 0.945 IN |
| Disc Finish | Fully Coated |
| Hat Finish | Coated |
| Overall Height | 59.400 MM |
| Overall Height | 2.339 IN |
| Outside Diameter | 258.100 MM |
| Outside Diameter | 10.161 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 64.500 MM |
| Center Hole Diameter | 2.539 IN |
| Mounting Bolt Hole Circle Diameter | 108.000 MM |
| Mounting Bolt Hole Circle Diameter | 4.252 IN |
| Stud/Lug Hole Quantity | 4 |
| Stud/Lug Hole Diameter | 14.400 MM |
| Stud/Lug Hole Diameter | 0.567 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00889590390995 |
CENTRIC 320.61023F Cross References
CENTRIC 320.61023F Fits Vehicles
- Mercury Cougar (1987-1988)
- Ford Thunderbird (1987-1988)
- Ford Mustang (1993)
