CENTRIC 320.51008 Part Description
Manufacturer
Product Description
Centric GCX Rotor with Partial Coating
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron FormulationEnhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
CENTRIC 320.51008 Specifications
Product Attributes
| Vane Style [cntrc] | Straight |
| Weight [cntrc] Kgs | 8.180 |
| Misc Holes [cntrc] | 2 |
| Weight [cntrc] Lbs | 18.000 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Disc Mounting [cntrc] | Floating |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 0.697 IN |
| Discard Thickness | 17.700 MM |
| Nominal Thickness | 19.000 MM |
| Nominal Thickness | 0.748 IN |
| Disc Finish | Partially Coated |
| Hat Finish | Coated |
| Overall Height | 52.000 MM |
| Overall Height | 2.047 IN |
| Outside Diameter | 241.000 MM |
| Outside Diameter | 9.488 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 2.480 IN |
| Center Hole Diameter | 63.000 MM |
| Mounting Bolt Hole Circle Diameter | 100.000 MM |
| Mounting Bolt Hole Circle Diameter | 3.937 IN |
| Stud/Lug Hole Quantity | 4 |
| Stud/Lug Hole Diameter | 12.500 MM |
| Stud/Lug Hole Diameter | 0.492 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590390643 |
CENTRIC 320.51008 Part Interchanges
| Brand | Part Number |
|---|---|
| Raybestos Brakes | 980098, 980098FZN, 980098R |
CENTRIC 320.51008 Cross References
We have 3 alternatives for the 320.51008 by CENTRIC:
