(888) 312-8812 Login SignupCENTRIC 320.42054 Centric GCX Rotor with Partial Coating
Tap to view 4 more
$3999
Limited availability at this price!
In Stock
Get it by Wednesday, Dec 17
CENTRIC 320.42054 Part Description
Manufacturer
Product Description
Centric GCX Rotor with Partial Coating
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron FormulationEnhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
CENTRIC 320.42054 Specifications
Product Attributes
| Product Grade [cntrc] | Premium |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Disc Mounting [cntrc] | Floating |
| Misc Holes [cntrc] | 2 |
| Weight [cntrc] Kgs | 2.610 |
| Weight [cntrc] Lbs | 5.750 |
| Discard Thickness | 0.236 IN |
| Discard Thickness | 6.000 MM |
| Nominal Thickness | 7.000 MM |
| Nominal Thickness | 0.276 IN |
| Disc Finish | Partially Coated |
| Hat Finish | Coated |
| Overall Height | 39.500 MM |
| Overall Height | 1.555 IN |
| Outside Diameter | 9.213 IN |
| Outside Diameter | 234.000 MM |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Solid |
| Bearings Included | No |
| Center Hole Diameter | 2.677 IN |
| Center Hole Diameter | 68.000 MM |
| Mounting Bolt Hole Circle Diameter | 100.000 MM |
| Mounting Bolt Hole Circle Diameter | 3.937 IN |
| Stud/Lug Hole Quantity | 4 |
| Stud/Lug Hole Diameter | 12.750 MM |
| Stud/Lug Hole Diameter | 0.502 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590389074 |
CENTRIC 320.42054 Part Interchanges
| Brand | Part Number |
|---|---|
| Raybestos Brakes | 96154, 96154R |
CENTRIC 320.42054 Cross References
We have 2 alternatives for the 320.42054 by CENTRIC:
