(888) 312-8812 Login SignupRAYBESTOS 8552 Raybestos Specialty - Truck Coated Brake Rotor
$518.98
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RAYBESTOS 8552 Part Description
Manufacturer
Product Description
Raybestos Specialty - Truck Coated Brake Rotor
Application Summary
2018-2004 Prevost High Decker Front, 2018-2004 Prevost High Decker Rear, 2019-2006 Motor Coach Industries D4505 Front, 2019-2006 Motor Coach Industries D4505 Rear, 2019-2015 Mack TerraPro Front, 2019-2015 Mack TerraPro Rear
Features & Benefits
- OE Fit, Form, and Function
- Our vehicle-specific design matches OE fit, form and function, providing ultimate strength and performance
- Cooling Vanes
- We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring: Optimal cooling Reduced fade Less noise Increased pad life
- Coating
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0® rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0(R) rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- SAE Standard for Tensile Strength
- Our rotors follow SAE standards for tensile strength, hardness, and iron grade, providing structural integrity and maximum service life
- Turned Finish
- A turned finish provides an excellent surface for the pads to engage with to ensure a smooth and effective stop right out of the box
RAYBESTOS 8552 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Bolt Thread Pitch | 0.059 IN |
| Bolt Thread Pitch | 1.5 MM |
| Center Hole Diameter | 8.201 IN |
| Center Hole Diameter | 208.3 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 1.457 IN |
| Discard Thickness | 37 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 10.512 IN |
| Mounting Bolt Hole Circle Diameter | 267 MM |
| Mounting Bolt Hole Diameter | 0.551 IN |
| Mounting Bolt Hole Diameter | 14 MM |
| Mounting Bolt Hole Quantity | 10 |
| Nominal Thickness | 1.772 IN |
| Nominal Thickness | 45 MM |
| Outside Diameter | 17.087 IN |
| Outside Diameter | 434 MM |
| Overall Height | 5.65 IN |
| Overall Height | 143.5 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 10 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213309331 |
RAYBESTOS 8552 Cross References
| Brand | Part Number |
|---|---|
| CENTRIC | 120.86001, 126.86001 |
| Centric Parts | 120.86001, 126.86001 |
| ConMet | 10080753, 10082181 |
| Dayton Walther | 123642, 125600 |
| DuraGo | BR95002204 |
| MCI | 15031012, 15031012CG |
| MERITOR | 23123642002 |
| Meritor | 23123642015 |
| TORQSTOP | RUM56642 |
| WEBB | 55060F |
| Webb | 55060P |
RAYBESTOS 8552 Fits Vehicles
- Mack TerraPro (2015-2019)
- Mack Granite (2015-2018)
- Prevost XL2 (2004-2009, 2011-2013)
- Prevost X3 Coach (2007-2018)
- Prevost Shell (2004, 2006-2008, 2010-2018)
- Prevost High Decker (2004-2018)
- Spartan Motors Metro Star (2003-2008)
- Spartan Motors Gladiator (2003-2008)
- Motor Coach Industries D4505 (2006-2019)
- Motor Coach Industries D4005 (2005-2009, 2011, 2013-2017)
