RAYBESTOS 8552 Raybestos Specialty - Truck Coated Brake Rotor

★★★★★ (0)

$518.98

MSRP Pricing shown.

Out of Stock

We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.

We may have similar parts for sale. Search Alternatives >

RAYBESTOS 8552 Part Description

Manufacturer

RAYBESTOS

Product Description

Raybestos Specialty - Truck Coated Brake Rotor

Application Summary

2018-2004 Prevost High Decker Front, 2018-2004 Prevost High Decker Rear, 2019-2006 Motor Coach Industries D4505 Front, 2019-2006 Motor Coach Industries D4505 Rear, 2019-2015 Mack TerraPro Front, 2019-2015 Mack TerraPro Rear

Features & Benefits

  • OE Fit, Form, and Function
  • Our vehicle-specific design matches OE fit, form and function, providing ultimate strength and performance
  • Cooling Vanes
  • We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring: Optimal cooling Reduced fade Less noise Increased pad life
  • We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring:Optimal coolingReduced fadeLess noiseIncreased pad life
  • Coating
  • All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0® rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
  • All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0(R) rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
  • SAE Standard for Tensile Strength
  • Our rotors follow SAE standards for tensile strength, hardness, and iron grade, providing structural integrity and maximum service life
  • Turned Finish
  • A turned finish provides an excellent surface for the pads to engage with to ensure a smooth and effective stop right out of the box

RAYBESTOS 8552 Specifications

Product Attributes

ABS Tone Ring IncludedNo
Bolt Thread Pitch0.059 IN
Bolt Thread Pitch1.5 MM
Center Hole Diameter8.201 IN
Center Hole Diameter208.3 MM
Conventional Or Drum-In-Hat Type RotorConventional
Discard Thickness1.457 IN
Discard Thickness37 MM
Harmonize Code8708.30.5030
Mounting Bolt Hole Circle Diameter10.512 IN
Mounting Bolt Hole Circle Diameter267 MM
Mounting Bolt Hole Diameter0.551 IN
Mounting Bolt Hole Diameter14 MM
Mounting Bolt Hole Quantity10
Nominal Thickness1.772 IN
Nominal Thickness45 MM
Outside Diameter17.087 IN
Outside Diameter434 MM
Overall Height5.65 IN
Overall Height143.5 MM
Salability RestrictionsNo
Solid Or Vented Type RotorVented
Stud/Lug Hole Quantity10
Surface TypeSmooth
UNSPSC Code25171715

Additional Information

Country of Origin (Primary)CN
Canadian Harmonizing Tariff Code8708309990
Harmonized Tariff Code (HTS)8708305030
UPC00887213309331

RAYBESTOS 8552 Cross References

BrandPart Number
CENTRIC120.86001, 126.86001
Centric Parts120.86001, 126.86001
ConMet10080753, 10082181
Dayton Walther123642, 125600
DuraGoBR95002204
MCI15031012, 15031012CG
MERITOR23123642002
Meritor23123642015
TORQSTOPRUM56642
WEBB55060F
Webb55060P

RAYBESTOS 8552 Fits Vehicles

  • Mack Granite (2015-2018)
  • Mack TerraPro (2015-2019)
  • Motor Coach Industries D4005 (2005-2009, 2011, 2013-2017)
  • Motor Coach Industries D4505 (2006-2019)
  • Prevost High Decker (2004-2018)
  • Prevost Shell (2004, 2006-2008, 2010-2018)
  • Prevost X3 Coach (2007-2018)
  • Prevost XL2 (2004-2009, 2011-2013)
  • Spartan Motors Gladiator (2003-2008)
  • Spartan Motors Metro Star (2003-2008)
