DELPHI TC1006 Part Description
DELPHI TC1006 Specifications
Product Attributes
| Position(s) | Front Lower |
| Item Grade | Standard Replacement |
| Material | Steel |
| Maximum Outside Diameter | 1.450 IN |
| Maximum Outside Diameter | 36.80 MM |
| Color | Silver |
| Stud Thread Diameter | 12 MM |
| Castle Nut Included | No |
| Grease Fitting Included | No |
| Suspension Grade Type | Standard |
| Bushings Included | No |
| Dust Boot Included | Yes |
| Ball Joint Assembly | Yes |
| Width | 75 MM |
| Type | Premium |
| Cotter Pin Included | No |
| Cotter Pin Hole | No |
| Mounting Hardware Included | Yes |
| Washers Included | No |
| Height | 2.560 IN |
| Height | 65.00 MM |
| Nuts Included | Yes |
| Mounting Hole Quantity | 0 |
| Stud Thread Length | 0.77 IN |
| Stud Thread Length | 19.5 MM |
| Wrench Size | 5mm |
| Stud Type | Threaded |
| Mounting Type | Press-In |
| Dust Boot Material | Rubber |
| Bushing Quantity | 0 |
| Mounting Bolts Included | Yes |
| Mount Plate Included | No |
| Tapered Stud | Yes |
| Stud Tapered End 2 Diameter | 0.65 IN |
| Stud Tapered End 2 Diameter | 16.5 MM |
| Stud Tapered End 1 Diameter | 0.53 IN |
| Stud Tapered End 1 Diameter | 13.5 MM |
| Stud Thread Pitch | 1.25 MM |
| Length | 75.00 MM |
| Mounting Bolt Length | 31.30 MM |
| Adjustable | No |
| Greaseable | No |
| Mounting Bolt Head Diameter | 16.00 MM |
| Mounting Bolt Thread Pitch | 2.25 MM |
| Mounting Bolt Thread Length | 26.00 MM |
| Length | 2.950 IN |
| Stud Thread Diameter | 0.47 IN |
| Mounting Bolt Length | 1.230 IN |
| Mounting Bolt Head Diameter | 0.630 IN |
| Mounting Bolt Thread Length | 1.020 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Country of Origin (Primary) | TR |
| UPC | 00689604297421 |
| VMRS Code | 016001015 |
| UNSPSC | 25174203 |
DELPHI TC1006 Part Interchanges
| Brand | Part Number |
|---|---|
| MOOG Chassis Products | K500118 |
| Toyota | 4330859035, 4330859095 |
| TRW | JBJ7537 |
| N/A | MK90310, B90310XL, GK90310, B90310 |
DELPHI TC1006 Fits Vehicles
- Toyota Prius C (2012-2019)
- Scion iQ (2012-2014)
- Scion xD (2008-2014)
- Toyota Yaris (2006-2017)
- Scion xB (2004-2006)
- Scion xA (2004-2006)
- Toyota Echo (2000-2005)
