*Representative image - actual part not displayed
$344.90
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 120.86028 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.86028 Specifications
Product Attributes
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Lbs | 37.000 |
| Disc Mounting [cntrc] | Behind the Hub |
| Weight [cntrc] Kgs | 81.400 |
| Misc Holes [cntrc] | 0 |
| Product Grade [cntrc] | Premium |
| Notes [cntrc] | U Shaped |
| Discard Thickness | 1.457 IN |
| Discard Thickness | 37.000 MM |
| Nominal Thickness | 45.000 MM |
| Nominal Thickness | 1.772 IN |
| Overall Height | 5.320 IN |
| Overall Height | 135.128 MM |
| Outside Diameter | 432.054 MM |
| Outside Diameter | 17.010 IN |
| Mounting Bolt Hole Quantity | 10 |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 134.900 MM |
| Center Hole Diameter | 5.311 IN |
| Mounting Bolt Hole Circle Diameter | 9.250 IN |
| Mounting Bolt Hole Circle Diameter | 234.950 MM |
| Hat Finish | Painted |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00889590377200 |
CENTRIC 120.86028 Cross References
CENTRIC 120.86028 Fits Vehicles
- MAN TGS (2015-2017)
- MAN TGX (2015-2018)
