ACDelco 18A2719AC - Disc Brake Rotor - 5 Lug Holes, Cast Iron, Coated, Plain Vented, Front
$8249
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
ACDELCO part description
Silver™ Disc Brake Rotor - Front, Vented
Product Description
Front Brake Rotor
Product Attributes
| Nominal Thickness | 30mm (1.181 in.) |
| Center Hole Diameter | 68.58mm (2.7 in.) |
| BOLT CIRCLE | 120mm (4.724 in.) |
| Lug Holes Quantity | 5 |
| Lug Holes Quantity | 5 |
| Minimum Thickness | 27mm (1.063 in.) |
| Quantity | 1 Per Pack |
| Quantity | 1 Per Pack |
| Rotor Construction | 1-Piece |
| Rotor Construction | 1-Piece |
| Rotor Design | Rotors Only |
| Rotor Design | Rotors Only |
| Rotor Diameter | 321mm (12.64 in.) |
| Rotor Diameter | 321mm (12.64 in.) |
| Rotor Finish | Coated |
| Rotor Finish | Coated |
| Rotor Height | 51.05mm (2.01 in.) |
| Rotor Material | Cast Iron |
| Rotor Material | Cast Iron |
| Rotor Style | Plain |
| Rotor Style | Plain |
| Rotor type | Vented |
| Rotor type | Vented |
| Rotor Vane Type | Non-Directional |
| Rotor Vane Type | Non-Directional |
| Discard Thickness | 1.063 IN |
| Inside Diameter | 7.5 IN |
| Height (in) | 2 in |
| Center Bore Diameter (in) | 2.7in |
| Bolt Circle Diameter (in) | 4.724 in |
| Bolt Hole Quantity | 5 |
| Width (in) | 13.31 in |
| Length (In) | 13.94 IN |
| Weight | 21.8 lb |
| Discard Thickness | 27 MM |
| Center Hole Diameter | 67.3 MM |
| Height (mm) | 50.8 mm |
| Center Bore Diameter (mm) | 68.6mm |
| Bolt Circle Diameter (mm) | 120 mm |
| Mounting Bolt Hole Circle Diameter | 4.72 IN |
| Inside Diameter | 190.5 MM |
| Product Description | ACDelco Advantage Coated Disc Brake Rotors provide reliable vehicle braking power. Their robotic-applied, baked-on coating helps prevent brake pulsation, helps prevent the rotor from seizing to the hub, and provides superior rust prevention against harsh environmental elements such as rain, snow, and corrosive road sprays. They feature a non-directional ground finish that helps to extend brake pad life and minimizes thickness variation. They are also ready to be installed right out of the box, with no machining required. These dependable aftermarket Advantage Coated Disc Brake Rotors offer quality at an economical price. ⚠<b> WARNING:</b> Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Material | Cast Iron |
| FAQ - Question 1 | Does ACDelco offer other grades of brake rotors? |
| Construction | Full Cast |
| Features & Benefits - Bullet 1 | Manufactured with multiple alloys for improved heat dissipation and performance |
| Features & Benefits - Bullet 2 | Mill-balanced for proper rotor function; no extra weights needed |
| Programming Required | No |
| Slotted | No |
| Disc Finish | Non Directional |
| Hat Finish | Plain |
| Features & Benefits - Bullet 3 | Quality validated for proper metallurgy and correct brake plate thickness |
| Grade Type | Regular |
| Features & Benefits - Bullet 4 | Rounded radius for added strength |
| Surface Type | Smooth |
| Signs of Wear & Troubleshooting - Section 1 - Bullet 4 | Vehicle pulls to the left or right when brakes are applied. |
| Solid Or Vented Type Rotor | Vented |
| Signs of Wear & Troubleshooting - Section 1 - Bullet 5 | Visible ridges or deep grooves on the rotor surface. |
| Rust Resistant Coating | Yes |
| FAQ - Answer 1 | Yes, ACDelco also offers GM OE brake rotors and Professional brake rotors. |
| Center Hole Diameter | 2.65 IN |
| Bearings Included | No |
| Mounting Bolt Hole Diameter | 0.638 IN |
| Mounting Bolt Hole Diameter | 16.2 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.181 IN |
| Nominal Thickness | 30 MM |
| Outside Diameter | 12.638 IN |
| Outside Diameter | 321 MM |
| Overall Height | 2.008 IN |
| Overall Height | 51 MM |
| Stud/Lug Hole Quantity | 5 |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Mounting Bolt Hole Circle Diameter | 119.9 MM |
| ABS Tone Ring Included | No |
| Directional or Non-Directional Brake Surface | Non-Directional |
Additional Information
| Warranty Special | 12 Months/Unlimited Miles Limited Warranty (Parts Only). Please see ACDelco.com for more details|24 Months/40,000 Kilometers Limited Warranty (Parts Only). Please see ACDelcocanada.com for more details |
| Harmonized Tariff Code (HTS) | 8708305030 |
| Country of Origin (Primary) | CN |
| Warranty Special UOM | TX |
| UPC | 00808709338604 |
Fits Vehicles
- Chevrolet Malibu (2013-2015)
- Chevrolet Corvette (2020-2023)
- Chevrolet Malibu Limited (2016)
- Chevrolet Impala (2014-2020)
- Buick Regal (2011-2017)
- Chevrolet Equinox (2010-2017)
- Buick Allure (2010)
- GMC Terrain (2010-2017)
- Buick LaCrosse (2010-2016)
- Chevrolet Camaro (2010-2015)
