(888) 312-8812 Login SignupBENDIX 103009R Relay Valve
Tap to view 5 more
$62.06
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
BENDIX 103009R Part Description
BENDIX 103009R Specifications
Product Attributes
| Balance / Primary Service Port | Not applicable to this part |
| Body Configuration | 2 SUP / 2 DEL (H) |
| Cautionary Note(s) | Not applicable to this part |
| Control / Secondary Service Port | 1/4-18 NPT |
| Control Port Orientation (CW from Front Face) | Not applicable to this part |
| Crack Pressure | 4.0 PSI |
| Delivery Port 1 | 1/2-14 NPT |
| Delivery Port 2 | 1/2-14 NPT |
| Delivery Port 3 | Not applicable to this part |
| Delivery Port 4 | Not applicable to this part |
| Delivery Port 5 | Not applicable to this part |
| Delivery Port 6 | Not applicable to this part |
| Delivery Port 7 | Not applicable to this part |
| Delivery Port 8 | Not applicable to this part |
| Exhaust Port | Dust Shield |
| Internal Supply Passage to Cover | Not applicable to this part |
| Market Indicator | Aftermarket Remanufactured |
| Maximum Operating Temperature | 200 AdegF (93 AdegC) |
| Minimum Operating Temperature | -40 AdegF (-40 AdegC) |
| Mounting | .96 IN x .40 IN Slot (4x) |
| Mounting Bracket Direction | Not applicable to this part |
| Mounting Bracket Location | Loose in Box |
| Mounting Orientation (CW from Front Face) | Not applicable to this part |
| Supply Port 1 | 3/4-14 NPT |
| Supply Port 2 | 3/4-14 NPT |
| TMC Washer | RV040 |
Additional Information
| Core Class | 69 |
| Core Group | 25 |
| Country of Origin (Primary) | MX |
| UPC | 04068078349489 |
| VMRS Code | 013010009 |
BENDIX 103009R Cross References
| Brand | Part Number |
|---|---|
| N/A | 103009RX, 296010N |
