(888) 312-8812 Login SignupWAGNER BD126311E Wagner Brake BD126311E Disc Brake Rotor
Tap to view 2 more
MSRP: $86.27
$5849
Save $27.78
Limited availability at this price!
In Stock
Get as soon as Monday, Nov 2
WAGNER BD126311E Part Description
Manufacturer
Product Description
Disc Brake Rotor
Application Summary
2005-2022 Toyota Tacoma Base (Front) (Drive: RWD / Qualifier: 5 Stud Wheel, with 275 Diameter Rotor, Black E-Coat on non-braking surface to prevent rust and corrosion)
Features & Benefits
- ENGINEERED FOR PERFORMANCE -- OE-specific vane design provides effective braking power and heat dissipation while controlling noise, vibration and harshness
- OE-STYLE DESIGN -- Restores like-new braking performance while matching OE fit, form and function
- PREMIUM PROTECTION -- E-Shield(R) protective coating is applied to non-braking surfaces to inhibit corrosion
- RESISTS CORROSION -- Painted edges & hats provide reliable corrosion resistance
- TURNED AND SMOOTH FINISH -- Requires less pad break-in time and aids in proper bedding
- NON-DIRECTIONAL FINISH -- Reduces pad break-in time and promotes proper bedding for consistent stopping power
- EASY INSTALLATION -- Rotors are packaged in a Vapor Corrosion Inhibitor bag, eliminating the need for an oil coating which reduces prep time
- CONSISTENT PERFORMANCE -- Precision ground surface finish delivers reliable performance, noise reduction and heat dissipation
- PROPER BALANCE -- Spin balanced and cut to limit vibration for improving stability and control
- SMOOTH BRAKING -- Application-specific OE vane design and thickness help control noise, vibration and harshness (NVH)
- PERFECT PAIRING -- Pair Wagner premium rotors with premium brake pads for optimal performance
- BALANCED FOR SMOOTH STOPS -- Precision-balanced to minimize pedal pulsation and deliver a smoother ride
- QUALITY MATERIALS -- Proven metallurgy provides structural integrity and heat dispersion for reliable performance
- EASY TO INSTALL -- Simply wash the oil off and bolt on; no machining required
- COMPREHENSIVE COVERAGE -- Available for foreign and domestic nameplates
- PERFECT PAIRING -- Pair Wagner® Standard rotors with Wagner brake pads and calipers (sold separately) for optimal performance
- PERFECT PAIRING -- Pair Wagner(R) Standard rotors with Wagner brake pads and calipers (sold separately) for optimal performance
WAGNER BD126311E Specifications
Product Attributes
| Material | Cast Iron |
| Nominal Thickness | 0.986 IN |
| Disc Finish | Directional |
| Construction | Full Cast |
| Rust Resistant Coating | Yes |
| Outside Diameter | 10.826 IN |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Height | 2.307 in |
| Part Description | Disc Brake Rotor |
| Nominal Thickness | 25.0 MM |
| Height | 58.6 MM |
| Stud/Lug Hole Quantity | 5 |
| Outside Diameter | 274.9 MM |
| Overall Height | 58.6 MM |
| Overall Height | 2.307 IN |
| Bearings Included | No |
| Directional or Non-Directional Brake Surface | Non-Directional |
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.445 IN |
| Center Hole Diameter | 62.1 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 23.0 MM |
| Discard Thickness | 0.906 IN |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Mounting Bolt Hole Diameter | 0.574 IN |
| Mounting Bolt Hole Diameter | 14.6 MM |
| Prop 65 Label (Yes/No) | No |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708305030 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00008536947998 |
| VMRS Code | 013017001 |
| UNSPSC | 25171715 |
WAGNER BD126311E Cross References
| Brand | Part Number |
|---|---|
| ACDelco | 18A2420SD, 18A2420A, 18A2420AC, 18A2420 |
| Aimco | 31428 |
| Autospecialty | JBR1120 |
| Bosch | 50011296 |
| BrakeBest Select Drum/Rotor | 980461RGS |
| CENTRIC | 120.44136 |
| Carquest Platinum Painted Rotors | YH145717P |
| Carquest Wearever | YH145717 |
| Centric Parts | 120.44136, 121.44136, 12044136, 12144136, 120.44136CRY, 320.44136F |
| DuraGo | BR900358, BR900358-01, BR900358-02 |
| Duralast | 44586 |
| Dynamic Friction Company | 600-76133, 604-76133 |
| NAPA BRAKES | 880461CR, RA880461, 48880461, 248880461 |
| PowerStop | JBR1120, JBR1120EVC |
| Pro-Series | C26311, PS44586 |
| Promax | 20-31428, 14-31428 |
| RAYBESTOS | 980461, 980461R |
| Raybestos Brakes | 980461, 980461R, 980461FZN, 980461R2, 980461PER |
| Toyota | 4351204040, 4351204041, 4351204052 |
| Winhere | UR007417 |
| Worldparts Synergy | WS1231428 |
WAGNER BD126311E Fits Vehicles
- Toyota Tacoma (2005-2023)
