WAGNER BD180275E Part Description
Manufacturer
Product Description
Disc Brake Rotor
Application Summary
2010-2016 Hyundai Genesis Coupe 3.8 R-Spec 2.0T R-Spec 3.8 Track 3.8 Ultimate (Front) (Qualifier: Black E-Coat on non-braking surface to prevent rust and corrosion, with Brembo Brake System / Note: 5 Stud Wheel, with 340mm Diameter Rotor)
Features & Benefits
- ENGINEERED FOR PERFORMANCE -- OE-specific vane design provides effective braking power and heat dissipation while controlling noise, vibration and harshness
- OE-STYLE DESIGN -- Restores like-new braking performance while matching OE fit, form and function
- PREMIUM PROTECTION -- E-Shield(R) protective coating is applied to non-braking surfaces to inhibit corrosion
- RESISTS CORROSION -- Painted edges & hats provide reliable corrosion resistance
- TURNED AND SMOOTH FINISH -- Requires less pad break-in time and aids in proper bedding
- NON-DIRECTIONAL FINISH -- Reduces pad break-in time and promotes proper bedding for consistent stopping power
- EASY INSTALLATION -- Rotors are packaged in a Vapor Corrosion Inhibitor bag, eliminating the need for an oil coating which reduces prep time
- CONSISTENT PERFORMANCE -- Precision ground surface finish delivers reliable performance, noise reduction and heat dissipation
- PROPER BALANCE -- Spin balanced and cut to limit vibration for improving stability and control
- SMOOTH BRAKING -- Application-specific OE vane design and thickness help control noise, vibration and harshness (NVH)
- PERFECT PAIRING -- Pair Wagner premium rotors with premium brake pads for optimal performance
- BALANCED FOR SMOOTH STOPS -- Precision-balanced to minimize pedal pulsation and deliver a smoother ride
- QUALITY MATERIALS -- Proven metallurgy provides structural integrity and heat dispersion for reliable performance
- EASY TO INSTALL -- Simply wash the oil off and bolt on; no machining required
- COMPREHENSIVE COVERAGE -- Available for foreign and domestic nameplates
- PERFECT PAIRING -- Pair Wagner® Standard rotors with Wagner brake pads and calipers (sold separately) for optimal performance
- PERFECT PAIRING -- Pair Wagner(R) Standard rotors with Wagner brake pads and calipers (sold separately) for optimal performance
WAGNER BD180275E Specifications
Product Attributes
| Material | Cast Iron |
| Nominal Thickness | 1.102 IN |
| Disc Finish | Directional |
| Construction | Full Cast |
| Rust Resistant Coating | Yes |
| Outside Diameter | 13.362 IN |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Height | 2.228 in |
| Part Description | Disc Brake Rotor |
| Height | 56.5 MM |
| Stud/Lug Hole Quantity | 5 |
| Outside Diameter | 339.3 MM |
| Overall Height | 56.5 MM |
| Overall Height | 2.228 IN |
| Nominal Thickness | 27.9 MM |
| Bearings Included | No |
| Directional or Non-Directional Brake Surface | Non-Directional |
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.720 IN |
| Center Hole Diameter | 69.1 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 26.0 MM |
| Discard Thickness | 1.024 IN |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Mounting Bolt Hole Circle Diameter | 4.499 IN |
| Mounting Bolt Hole Diameter | 0.490 IN |
| Mounting Bolt Hole Diameter | 12.5 MM |
| Prop 65 Label (Yes/No) | No |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708305030 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00008536950677 |
| VMRS Code | 013017001 |
| UNSPSC | 25171715 |
WAGNER BD180275E Cross References
| Brand | Part Number |
|---|---|
| ACDelco | 18A2730 |
| ADVICS | R6F295U |
| Autospecialty | JBR1529 |
| Bosch | 28011493 |
| Carquest Wearever | YH274779 |
| Centric Parts | 120.51036, 121.51036, 12051036, 12151036, 125.51036, 125.51036CRY, 320.51036H |
| DuraGo | BR900796 |
| Duralast | 44677 |
| Dynamic Friction Company | 604-03032, 600-03032 |
| Hyundai | 517122M700 |
| NAPA BRAKES | 48880766, 248880766 |
| PowerStop | JBR1529, JBR1529EVC |
| Pro-Series | C08968, PS44677 |
| Promax | 14-31546, 20-31546 |
| Raybestos Brakes | 980766R, 980766FZN, 980766 |
| Winhere | 6621174, UR006076 |
| Worldparts Synergy | WS1331547 |
WAGNER BD180275E Fits Vehicles
- Hyundai Genesis Coupe (2010-2016)
