Champion 7166 - Double Platinum™ Spark Plug
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
CHAMPION part description
Product Description
Double Platinum Power Spark Plug KC6PYPB Carton of 4
Application Summary
VW, Audi, Porsche, 2.0, 3.0, 4.2, 5.2 liter
Features & Benefits
- Double Platinum Power - Premium Spark Plug. More Powerful Performance.
- Platinum center and ground electrode for greater wear resistance
- Maintains stable operating temperature under all engine loads
- Fine-wire center electrode for greater ignitability
- V-trimmed ground electrode promotes sharper spark focus
- Heat-ActiveTM alloy allows electrodes to reach optimal temperature
Product Attributes
| Ground Electrode Tip Design | J Gap |
| Ground Electrode Core Material | Platinum |
| Washer Included | Yes |
| Electrical Terminal Type | Non-Removable Nut |
| Center Electrode Tip Material | Platinum |
| Pre-Gap Size | 0.028 IN |
| Ground Electrode Quantity | 1 |
| Hex Size | 0.625 IN |
| Insulator Height | 0.059 IN |
| Manufacturer Heat Range | 6 |
| Seat Type | Flat |
| Reach | 0.75 IN |
| Thread Diameter | 0.551 IN |
| Resistor Type | Yes |
| Ground Electrode Tip Material | Platinum |
| 9459 | No |
| 9507 | Hex |
| 9608 | Fine Wire |
| 9745 | Crush |
| 9746 | No |
| Classification | Champion Double Platinum Power |
| Gap Style | J Gap |
| Ground Electrode Material | Platinum Pad Surface |
| Insulator Projection (inch) | 0.059 IN |
| Part Description | Spark Plug |
| Plug Type | KC6PYPB |
| Pre-Gap Size | 0.7 MM |
| Hex Size | 15.88 MM |
| Thread Diameter | 14 MM |
| Title | Champion Double Platinum - Boxed |
| Grade Type | Premium |
| Subject To Prop 65 (yes/no) | No |
Additional Information
| Country of Origin (Primary) | FR |
| Harmonized Tariff Code (Schedule B) | 8511100000 |
| Harmonized Tariff Code (HTS) | 8511100000 |
| Refurbished Part | N |
| Remanufactured Part | N |
| UPC | 00037551014644 |
| VMRS Code | 033003005 |
Part Interchanges
- Bosch FR5KPP332S
- Bosch FR6KPP332S
- Champion Spark Plug KC6PYPB
- NGK 94460
- NGK PFR8S8EG
- Beru Z347
- Audi 06H905601A
- Audi 06H905621
- Audi 101905631
- Audi 101905631B
- Audi 101905631H
- Volkswagen 06H905601A
- Volkswagen 06H905611
- Volkswagen 06H905621
- Volkswagen 06H905621A
- Volkswagen 101905631
- Volkswagen 101905631B
- Volkswagen 101905631H
- DENSO IK24
Fits Vehicles
- Audi TTS Quattro (2009-2015)
- Volkswagen Golf R (2012-2013)
- Volkswagen Tiguan Limited (2018)
- Audi Q3 Quattro (2015-2018)
- Audi Q3 (2015-2018)
- Audi A4 allroad (2013-2016)
- Audi allroad (2013-2016)
- Audi A3 Quattro (2009-2013)
- Audi SQ5 (2014-2017)
- Volkswagen Golf (2013)
- Audi RS5 (2013-2015)
- Audi A8 Quattro (2013-2017)
- Volkswagen Beetle (2012-2013)
- Audi A6 (2012-2015)
- Porsche Panamera (2012-2016)
- Audi A7 Quattro (2012-2017)
- Volkswagen Touareg (2011-2015)
- Audi Q7 (2011-2015, 2017)
- Audi R8 (2011-2012, 2014-2015, 2017-2018, 2020-2021)
- Audi Q5 (2011-2017)
- Porsche Cayenne (2011-2018)
- Audi A5 (2010-2014)
- Volkswagen Passat CC (2009-2010)
- Audi S5 (2010-2017)
- Audi S4 (2010-2016)
- Audi A5 Quattro (2010-2017)
- Volkswagen CC (2009-2017)
- Volkswagen GTI (2006-2014)
- Volkswagen Tiguan (2009-2017)
- Audi TT Quattro (2009-2015)
- Audi A6 Quattro (2009-2018)
- Audi TT (2008-2009)
- Volkswagen Eos (2007-2016)
- Volkswagen Passat (2006-2010)
- Volkswagen Jetta (2006-2010)
- Audi A3 (2006-2013)
- Audi A4 Quattro (2005-2016)
- Audi A4 (2005-2016)
