(888) 312-8812 Login SignupBALDWIN RS3516 Engine Air Filter - Radial Seal Element used for Freightliner, Peterbilt Trucks
MSRP: $165.34
$12249
Save $42.85
Limited availability at this price!
In Stock
Get it by Friday, Jul 31
BALDWIN RS3516 Part Description
Manufacturer
Product Description
Radial Seal Outer Air Element
Application Summary
Cummins Engs; Freightliner, PBTrucks
Features & Benefits
- Cylindrical element body features durable outer wrap construction
- Reinforced end caps provide structured edge support and integrity
- Radial seal flange forms a tight perimeter seating surface
- Engineered media maintains consistent airflow under varying operating conditions
Radial Seal Outer Air Element
Baldwin Radial Seal Air Filter Element
The Baldwin Radial Seal Air Filter Element directs incoming intake air through a controlled filtration path before it reaches the engine’s combustion chambers. As air is drawn in under throttle demand, suspended dust and airborne debris are trapped within the internal media structure, allowing cleaner airflow to continue downstream. Its radial sealing design presses firmly into the housing to help prevent bypass around the perimeter. This element is specified for Cummins engines as well as Freightliner and Peterbilt trucks, and it serves as a direct interchange for Donaldson P531026. The Baldwin RS3516 manages intake air filtration across compatible heavy-duty platforms.
BALDWIN RS3516 Specifications
Product Attributes
| Fits | Freightliner, Peterbilt Trucks |
| Replaces | Donaldson P531026 |
| Remark 2 | One End |
| Related to | {RS3516XP} (Extreme Performance Nano Media) |
| Outside Diameter 1 (mm) | 235.7 |
| Outside Diameter 1 | 9 9/32 |
| Inside Diameter 1 (mm) | 146.8 |
| Inside Diameter 1 | 5.78125 |
| Height (mm) | 595.3 |
| Height | 23 7/16 |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8421310000 |
| UPC | 00791440026209 |
BALDWIN RS3516 Cross References
| Brand | Part Number |
|---|---|
| LAF2536, BALRS3516, BLDRS3516 | |
| AFE | 70-10052, 70-50052, 70-70052 |
| AIR REFINER | ARM531026 |
| ALLIANCE | ABPN10GAF25219 |
| BALDWIN FILTERS | RS3516 |
| BIG A FILTER | 94842 |
| CARQUEST | 88842 |
| CHAMPION LABORATORIES | LAF2536 |
| DONALDSON | P531026, P605322, P535788, P534096, P534095, P185106, EAF5106 |
| FLEETGUARD | AF26657, AF25525, AF25219 |
| FLEETRITE | AFR825525, AFR825219 |
| FRAM | CA7727, CA8226 |
| GONHER | GA518R |
| GPC | FC2195 |
| GRAINGER | 2KYY6 |
| HASTINGS | AF2216 |
| IHC INTERNATIONAL HARVESTER | 1698941C1 |
| K & N ENGINEERING | 382022S |
| KRALINATOR | LA1533 |
| LUBER-FINER | LAF2536 |
| MACK | 3076CA7727 |
| NAPA GOLD | 6842 |
| PHOENIX | NA3566 |
| PUROLATOR | A75081 |
| TORQUE PARTS | TR515-EF |
| WIX | 546842, 46842 |
| WIX FILTERS | WIX FILTERS, 46842 |
BALDWIN RS3516 Fits Vehicles
- Freightliner FLB (1994-1999, 2002)
- Freightliner FLA086 (1989-1995, 1999)
- Peterbilt 386 (2006-2015)
- Peterbilt 377 (1996-2001)
- Peterbilt 384 (2008-2015)
- Peterbilt 385 (1995-2008)
- Peterbilt 357 (2001-2008)
- Peterbilt 387 (2000-2011)
- Freightliner Argosy (1999-2012, 2014-2015)
- International 9800 SBA (1996-1999)
BALDWIN RS3516 Customer Reviews
No reviews yet
Be the first to review this product!
BALDWIN RS3516 Manufacturer Information
Baldwin® is a world-renowned leader in the engine mobile filtration. A brand of Parker Engine Mobile Aftermarket Division (E.M.A.M.), Baldwin Filters provides high-quality filtration products and services for engines and mobile equipment. Since 1936, J.A. Baldwin, the founder of Baldwin Filtration, has recognized the importance of a highly efficient mobile filtration system. It is what inspired him to design an improved lube filter and set off its production in Wisconsin. Currently, Baldwin offers outstanding product quality, a vast distribution network, and one of the industry's most comprehensive product lines. Baldwin's broad range of filtration products and technologies provides customers with a one-stop source for all their engine and mobile filtration needs.
