(888) 312-8812 Login SignupBALDWIN PF7930 Fuel Water Separator Filter - used for Various Truck Applications
MSRP: $55.17
$3899
Save $16.18
Limited availability at this price!
In Stock
Get it by Friday, Feb 20
BALDWIN PF7930 Part Description
Manufacturer
Product Description
Fuel/Water Separator Element
Application Summary
Davco Housings
Features & Benefits
- Extracts 99% of free and emulsified water to protect high-pressure fuel pumps
- Fits Davco FH230 Series Fuel Pro and FH234 Series Industrial Pro processors with a precision OE-spec design
- Includes an internal relief valve and two O-rings to maintain proper pressure regulation and seal integrity
- Utilizes a pre-attached grommet to simplify installation and ensure a positive mechanical fit inside the housing
- Protects small injector orifices from microscopic grit and soot that cause internal scarring
- Supports high flow rates required by modern diesel engines, even during high-viscosity cold-weather starts
Fuel/Water Separator Element
Baldwin Fuel Water Separator Filter
Protecting the mechanical integrity of a high-pressure common rail fuel system requires the specialized filtration found in the Baldwin Fuel Water Separator Filter. Designed specifically for the Davco Fuel Pro 230 and Industrial Pro 234 series housings, this element captures both fine sediment and emulsified water before they can reach sensitive fuel injectors. The 6.93-inch tall filter features an integrated relief valve and a pre-attached grommet to ensure a secure, leak-free seat within the processor. While moisture in diesel fuel often leads to internal pump corrosion and power loss, the high-capacity cellulose media in this Baldwin PF7930 element strips out contaminants to preserve the engine's peak performance.
BALDWIN PF7930 Specifications
Product Attributes
| Replaces | Davco 102528; Paccar 382951PAC25; Volvo 21737499, 85120233; Fleetguard FS19765 |
| Remark 2 | One End |
| Outside Diameter 1 (mm) | 106.4 |
| Outside Diameter 1 | 4 3/16 |
| O-Ring | [2] Included |
| Inside Diameter 1 (mm) | 16.7 |
| Inside Diameter 1 | 21/32 |
| Height (mm) | 176.2 |
| Height | 6.9375 |
| Grommets | [1] Attached |
| Fits | Davco FH230 Series Fuel Pro, FH234 Series Industrial Pro |
| Contains | Relief Valve |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8421230000 |
| UPC | 00791440079687 |
BALDWIN PF7930 Cross References
| Brand | Part Number |
|---|---|
| BALPF7930, BLDPF7930 | |
| BALDWIN FILTERS | PF7930 |
| CARQUEST | 96005 |
| DAVCO | 102528 |
| DONALDSON | P550851 |
| FLEETGUARD | FS19765, FH23453, FH23477, FH23448, FH23447, FH23435, FH23069M, FH23068M, FH23067M, FH23060 |
| GRAINGER | 4ZKC5 |
| HASTINGS | FF1263 |
| HITACHI | E12981398 |
| LUBER-FINER | L9765FXL |
| MACK | 5839FS19765, 21737481 |
| NAPA GOLD | 601005 |
| PACCAR | 382951PAC25 |
| VOLVO | VOE85120233, VOE21737499, 85120233, 21737499 |
| WIX | WF10005, SF10005 |
| WIX FILTERS | WF10005 |
BALDWIN PF7930 Fits Vehicles
- International HX520 (2025)
- International HX620 (2022-2024)
- International HV513 (2022, 2025)
- Kenworth W990 (2022)
- Volvo VNL 860 (2019)
- Western Star 4900EX (2018)
- International HV613 (2020, 2022, 2026)
- Volvo VNL 760 (2019)
- Mack LR (2019)
- Mack Granite (2019-2020, 2023)
- Volvo VNL 630 (2015-2016)
- International RH613 (2018, 2022)
- International LT625 (2017-2018, 2021-2024)
- Volvo VNX (2015)
- Peterbilt 386 (2011-2013)
- Volvo VNL 740 (2019)
- International HX515 (2019, 2021)
- Volvo VNL 430 (2015-2016)
- Volvo VNL 300 (2016)
- Mack Pinnacle (2019-2020)
- Volvo VNR (2018-2019)
- Peterbilt 320 (2018)
- Mack TerraPro (2019)
- International WorkStar 7600 (2019)
- Mack Anthem (2019-2020)
- Mack LR600 (2016-2017, 2019)
- Volvo VNL 670 (2015-2016)
- Peterbilt 520 (2018, 2021-2022)
- Peterbilt 579 (2013-2019, 2022)
- Volvo VNM (2007-2018)
- Volvo VAH (2011-2020)
- Volvo VNL (2007-2019)
- Volvo VHD (2011-2019)
- Mack TD700 (2010-2017)
- Kenworth T700 (2011-2016)
- Peterbilt 389 (2014-2018, 2021-2022)
- Mack CHU (2008-2019)
- Peterbilt 388 (2008-2015)
- Peterbilt 367 (2011-2018, 2020-2021)
- Kenworth T880 (2014-2018, 2020-2021)
- Kenworth T680 (2013-2018)
- Mack GU8 (2008-2017, 2019)
- Mack GU7 (2008-2017, 2019)
- Mack CXU (2008-2017, 2019)
- Kenworth T660 (2011-2015)
- Peterbilt 384 (2011-2015)
- Peterbilt 365 (2011-2018, 2020-2021)
- Peterbilt 567 (2014-2019, 2021)
- Mack GU5 (2012-2017)
- Mack MRU (2008-2017)
- Mack LEU (2008-2015)
- Mack GU4 (2012-2017)
- Kenworth W900 (1999-2000, 2002-2018)
- Kenworth T800 (1999-2000, 2002-2018)
- International ProStar (2008-2018)
- International LoneStar (2009-2017)
- International 8600 SBA (2003-2007)
- Caterpillar CT660 (2013-2016)
BALDWIN PF7930 Customer Reviews
No reviews yet
Be the first to review this product!
BALDWIN PF7930 Manufacturer Information
Baldwin® is a world-renowned leader in the engine mobile filtration. A brand of Parker Engine Mobile Aftermarket Division (E.M.A.M.), Baldwin Filters provides high-quality filtration products and services for engines and mobile equipment. Since 1936, J.A. Baldwin, the founder of Baldwin Filtration, has recognized the importance of a highly efficient mobile filtration system. It is what inspired him to design an improved lube filter and set off its production in Wisconsin. Currently, Baldwin offers outstanding product quality, a vast distribution network, and one of the industry's most comprehensive product lines. Baldwin's broad range of filtration products and technologies provides customers with a one-stop source for all their engine and mobile filtration needs.
BALDWIN PF7930 Questions & Answers
No questions yet
Be the first to ask a question about this product!
