Name: Haldex KN20607 Manifold Dash Valve - Vertical Mounting, Air Supply and Parking Brake, 3/8 in. Ports
SKU: kn20607
Price: 380.49 USD
Availability: InStock

HALDEX part description

Product Description

Manifold Dash Valve

Features & Benefits

A completely serviceable valve designed with customer in mind
Made with Engineering Grade Composite (EGC) - one-piece housing
Built to last longer than the competing brand
A perfect replacement valve at a budget-friendly price

Haldex Hand Operated Valve

The Haldex hand operated valve enables the user to manually reduce incoming pressure to the desired output pressure. Manufactured by a brand with over 100 years of engineering expertise, this hand control valve delivers superior performance, reliability, and efficiency.

Product Attributes

Auxiliary Supply Port	.375 in.
Delivery Port Trailer	.375 in.
Exhaust Port	3/8" PTC
Freight Class	70
Mounting (4 holes)	Vertical - M6 Metric nuts on cover
Non-Override Pressure	25 ± 5 PSI
Reservoir Port	2 @ .375 PTC
Spools	2
Tractor Delivery Port	.375 in.
Tractor Valve	20 - 35 PSI
Trailer Valve	20 - 45 PSI

Additional Information

Country of Origin (Primary)	MX
Harmonized Tariff Code (Schedule B)	8481200070
Harmonized Tariff Code (HTS)	8481200070
Remanufactured Part	N
Warranty Distance	100000
Warranty Distance UOM	MI
Warranty Special	36 MO, 350,000 MI=Haldex Air Brake Valves(1), Automatic Drain Valves (410-10XXX Series)(1). 12 MO, 100,000 MI= Automatic Drain Valves (N20878/ N20879 Series), Height Control Valve, Scale-O-Matic and AC Boxes. See L20221W.pdf for warranty details
Warranty Time	12
Warranty Time UOM	MO
UPC	00767653097411
VMRS Code	013010050

Part Interchanges
