(888) 312-8812 Login SignupBALDWIN BF1224 Fuel Water Separator Filter - used for Carrier-Transicold Refrigeration Units
MSRP: $93.90
$3449
Save $59.41
Limited availability at this price!
In Stock
Get it by Friday, Jul 17
BALDWIN BF1224 Part Description
Manufacturer
Product Description
Fuel/Water Separator Spin-on
Application Summary
Carrier-Transicold Refrigeration Units
Features & Benefits
- With water-separating media that promotes moisture collection away from fuel flow
- Has internal treatment to limit microbial buildup during extended idle periods
- Offers Carrier-Transicold–specific fit to maintain proper thread and gasket engagement
- Uses a sealing ring that remains effective in sub-zero operating conditions
- Provides a drain feature that allows quick water removal during routine inspections
Fuel/Water Separator Spin-on
Baldwin Fuel Water Separator Filter
The Baldwin Fuel Water Separator Filter is a spin-on solution developed for fuel systems used in Carrier-Transicold refrigeration units operating in variable duty cycles. Designed for equipment that often runs intermittently, this filter focuses on maintaining fuel quality during both operation and extended standby periods. Its water-separating media encourages moisture to collect away from the fuel stream, helping preserve injector and pump condition over time. The filter is also formulated to reduce the buildup that commonly occurs in stored ULSD and biodiesel blends. Proper thread engagement and gasket contact allow it to seat securely on Carrier-Transicold fuel heads without adjustment. Built for compact diesel platforms, the Baldwin BF1224 offers dependable water control and fuel cleanliness where refrigeration uptime depends on stable fuel delivery.
| Type | Spin On |
BALDWIN BF1224 Specifications
Product Attributes
| Height (mm) | 150 |
| Outside Diameter 1 | 4.25 |
| Integral Gasket | [1] Included |
| Outside Diameter 1 (mm) | 108 |
| Per Inch | 14 |
| Related to | {BF1223} (Drain Version);{BF1223-O} (Open End Version);{BF1223-SP} (Drain and Sensor Port Version) |
| Replaces | Carrier 30-01090-00 |
| Thread | 1 |
| Height | 5.90625 |
| Fits | Carrier-Transicold Refrigeration Units |
| Contains | Integral Post Seal |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8421230000 |
| UPC | 00791440045033 |
BALDWIN BF1224 Cross References
| Brand | Part Number |
|---|---|
| FF5301, LFF1224, BALBF1224, BLDBF1224 | |
| ACDELCO | TP1285 |
| ALCO FILTERS | SP1431 |
| ALLIANCE | ABPN10GFF5301 |
| BALDWIN FILTERS | BF1224 |
| BIG A FILTER | 95411, 95404, 95231 |
| BOMBARDIER | 921144764 |
| BUHLER VERSATILE | 86029160 |
| CAPACITY | 111898 |
| CARQUEST | 86404 |
| CARRIER | 30-01090-00 |
| CARRIER TRANSICOLD | 30-01090-00 |
| CARRIER-TRANSICOLD | 300109900, 3001099, 300109005, 300109004, 300109000, 3001090, 300107900, 3001079 |
| CASE | 87803210, 87802929 |
| CHAMPION LABORATORIES | LFF8063, LFF5766, LFF1225, LFF1224, LFF1223 |
| DONALDSON | P559125, P551852, P551056, P550730, P550548, P550455, FFP551852 |
| FLEETGUARD | FF5301, FS19687 |
| FLEETRITE | FFR85301 |
| FORD MOTOR | F1HZ9365A, F08N9176AA, 87840136, 6933130 |
| FRAM | PS7171, PS8187 |
| GONHER | GPP1287, GP1224 |
| GRAINGER | 2KZA8, 2KYJ8 |
| GREYFRIARS | 857S |
| HASTINGS | FF1044 |
| HENGST | H7060WK10 |
| HINO | S234011440, 234021440, 234011630, 234011440L, 234011440A, 234011440 |
| IHC INTERNATIONAL HARVESTER | 1685359C91 |
| IVECO | 87840136, 7146717 |
| JCB (J.C. BAMFORD) | 32925218 |
| JURA (HIFI) | SN906010 |
| KRALINATOR | FS239R, FS239 |
| LUBER-FINER | LFF1224 , LFF8063, LFF5766, LFF1225, LFF1223, LFF1224 |
| MACK | 5839FF5301, 3076PS8187, 3076PS7171 |
| MAHLE | KC379D, 70385369, 70385367, 70385362, 70385361 |
| MANN+HUMMEL | WK11421X |
| MOTORCRAFT | FD3368 |
| NAPA GOLD | 3411, 3404, 3231 |
| NEW HOLLAND | 87840136, 87803210, 87802929, 6933130 |
| PREMIUM GUARD | DW30264 |
| PUROLATOR | F65041, 6938309 |
| RACOR | R60T, R44, PFF3368, PFF831 |
| SAKURA | SFC1904, SFC190102, SFC130630, SFC130610, SFC130602 |
| SURE FILTER TECHNOLOGY | SFR2240FW, SFF1440 |
| VERSATILE | 86029160 |
| WIX | 533404, 33411, 33404, 33231 |
| WIX FILTERS | 33404 |
| WOODGATE | WGFS1223 |
BALDWIN BF1224 Fits Vehicles
- Ford F-600 LPO (1990-1994)
- Hino FD2320 (2004)
- Hino SG3325 (1998-2004)
- Hino FD2220 (1998-2002)
- Hino SG3320 (1998-2001)
- Hino FF3020 (1998-2002, 2004)
- Hino FE2620 (1998-2004)
- Hino FB1817 (1998-2004)
- Hino FA1517 (1998-2004)
- Hino 338CT (2008-2014)
- Ford CF8000 (1991-1994)
- Ford B-600 (1987-1993)
- Ford B-700 (1987-1993)
- Ford LN7000 (1987-1993)
- Ford LN8000 (1991-1993)
- Ford F-800 (1986-1993)
- Ford F-700 (1991-1993)
- Ford F-600 (1980-1994)
- Ford CF7000 (1986-1993)
- Ford CF6000 (1986-1990)
- Hino 338 (2005-2014)
BALDWIN BF1224 Customer Reviews
No reviews yet
Be the first to review this product!
BALDWIN BF1224 Manufacturer Information
Baldwin® is a world-renowned leader in the engine mobile filtration. A brand of Parker Engine Mobile Aftermarket Division (E.M.A.M.), Baldwin Filters provides high-quality filtration products and services for engines and mobile equipment. Since 1936, J.A. Baldwin, the founder of Baldwin Filtration, has recognized the importance of a highly efficient mobile filtration system. It is what inspired him to design an improved lube filter and set off its production in Wisconsin. Currently, Baldwin offers outstanding product quality, a vast distribution network, and one of the industry's most comprehensive product lines. Baldwin's broad range of filtration products and technologies provides customers with a one-stop source for all their engine and mobile filtration needs.
