(888) 312-8812 Login SignupBALDWIN B7290 Lube Spin-on
$1249
Limited availability at this price!
In Stock
Get it by Thursday, Jul 9
BALDWIN B7290 Part Description
Manufacturer
Product Description
Lube Spin-on
Application Summary
Cat, Lombardini, Ruggerini Engs
Lube Spin-on
BALDWIN B7290 Specifications
Product Attributes
| Contains | Anti-Drainback Valve;14 PSID By-Pass Valve |
| Fits | Caterpillar, Lombardini, Ruggerini Engines |
| Height | 3.875 |
| Outside Diameter 1 | 3 |
| Thread | 4-Mar |
| Replaces | Lombardini 500.217.536; Woodgate WGL3338 |
| Per Inch | 16 |
| Outside Diameter 1 (mm) | 76.2 |
| Integral Gasket | [1] Included |
| Height (mm) | 98.4 |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8421230000 |
| UPC | 00791440072084 |
BALDWIN B7290 Cross References
| Brand | Part Number |
|---|---|
| BLDB7290 | |
| ACDELCO | X72 |
| ALBIN | 48495 |
| ALCO FILTERS | SP949 |
| AMERICAN MOTORS CORP. | TO134, NO244 |
| AMERICAN PARTS | 92625, 92288, 2055 |
| AP LOCKHEED | LK3568, LK3862, LK1030, LK1010, AP76200A, AP3568, AP3472A, AP3472, AP3099A, AP3267A, AP3204A, AP1011, AP1010 |
| ASV | YM17213173740, 17213173740 |
| ATLAS COPCO | 29148058 |
| AUTOPAR | FE254 |
| BALDWIN FILTERS | B7290 |
| BOMAG | 5710631 |
| BOSCH | 986452038, 986452019, 9457282190, 451163019, 451103080, 451103073, 451103048, 451103036, 451103035, 451103034, 451103027, 45103034 |
| CARQUEST | 94264 |
| CASE | 78641C1 |
| CATERPILLAR | 817003, 1767710 |
| CHAMPION | C304 |
| CHAMPION LABORATORIES | C204, C104 |
| CHRYSLER | P4452889, MD108063 |
| CLEAN FILTERS | DO286 |
| COMPAIR | C160121032 |
| CONTINENTAL AG | PC3614A |
| COOPERS | Z85, Z809, Z696, Z1008, Z516, Z508, Z173, Z121, AZL005 |
| CROSLAND | Z876, 591, 355, 349, 2144, 2066 |
| DAIHATSU | 1651073010, 1651073001, 1651073000, 1560187103999 |
| DEUTZ | A0484123 |
| DONALDSON | P779621 |
| DONIT | 431094, 4310128 |
| EXXON/MOBIL OIL | M1102, M1102A |
| FAUN FRISCH | 147246 |
| FENWICK | 8102165 |
| FIAAM | FT4985, FT4960, FT4949, FT4930, FT4857, FA4401 |
| FIAT | 5939831, 4434792 |
| FILCA | FL28US |
| FILTER CONTROL LTD. | FCL7249, FCL7247, FCL7237, FCL7350, FCL7297 |
| FIRESTONE | TF346 |
| FISPA | FOE160, FOE159 |
| FORD MOTOR | DOAY6731A, A81OX6714HA, A810X6714GA, A800X6714CA, A780X6714RA, 77BM6714CIA, 6141811, 60666095, 6057167, 6057166, 79AX6714CA, 5008719, 5008718, 5003271, 3254957, 5005573, 5005097, 1555370, 1462805 |
| FRAM | PH46A, PH4482, PH2966, PH2919, PH2885A, PH2884, M1-102A, M1-102 |
| FRAM EUROPE (SOGEFI) | PH2954 |
| GEHL | 88361 |
| GM GENERAL MOTORS | 93156186, 9975227, 21000872 |
| GONHER | GP3816, GP2951 |
| GRAINGER | 3XUG9 |
| GREYFRIARS | 990S, 980S, 919S, 9069S |
| GUARDIAN FILTER CO. | G051374, G051348 |
| GUD FILTERS | Z500 |
| GUIOT | GH2919, GH2885, GH2855 |
| GULF | GF209 |
| HASTINGS | B7290 |
| HENGST | H90W20, H90W05, H901W01, H14W13 |
| INGERSOLL RAND | 92824598, 59769265 |
| JIMCO | JOC15003 |
| KNECHT | FO318C10, AW541, AW52C10, AW37 |
| KOMATSU | PK140516190 |
| KRAMER | 3634334 |
| LANCER BOSS | 207818 |
| LANSING BAGNALL | E725006049 |
| LAUTRETTE | ELHA4065, ELH4101, ELH4085, ELH4027, EL4300 |
| LEYLAND | ADU7323, ADU7322, ADU7321, 13H9104, 13H9090, 12G2400 |
| LOMBARDINI | 500.217.536, 500217536, 2175040 |
| LUBER-FINER | PH2835 |
| LUCAS | 3760, 3758, 3705, 2022 |
| M FILTER | MH395, MH374 |
| MAHLE | OC98, OC96, OC82, OC182, AW141, AW118, AW106, C4, AW93, AW75 |
| MANITOU | 136508 |
| MANN+HUMMEL | W9149X, W91415, W91411, W71210, W81181, W7121 |
| MANN-HUMMEL FILTERS | L10241, W811/81, W712/83 |
| MANUSUR | T9091503001 |
| MASTE | DK92, DK51, DK35 |
| MAZDA | RF1023802A |
| MICRO PORE | T1634 |
| MOBIL OIL | M1102A, M1-102 |
| MOTAQUIP | VFL180, 75221627, 75066464 |
| MOTORCRAFT | EFL88, EFL253, EFL168, EFL163, EFL144, EFL134 |
| MP FILTRI | CSG30BP10A, C33445 |
| NAPA GOLD | 1339 |
| NEM | NE241, NE138 |
| NIPPON | T1632 |
| NKK | 4TP119 |
| O&K ORENSTEIN & KOPPEL | 1447560, 103952 |
| OPEL | 650373, 650365, 650364 |
| PACIFIC MFG. CO. | PE811, PE397 |
| PBR | BC1226, BC1158, BC1149 |
| PURFLUX | LS504, LS205, LS194B, LS188B |
| PUROLATOR | TBO241, PM206A, PER163, PC258, PER263, MF6200A, FC141, FC1141, FC114, FC0258, TL10241, TL10241BP, L10241, PL10241, PBL10241 |
| RANSOMES, SIMMS & JEFFRIES | 5000440 |
| RENAULT | 7700638670, 7700545868, 5000789225 |
| RUGGERINI | 17522 |
| RYCO | Z172 |
| SAVARA | 928436, 928434, 928431, 92835400 |
| SF-FILTER / SCHUPP | SP4212 |
| SOPARIS | CV447, CV445, CV436, CV426, CV398M, CV398, CAP273 |
| STEYR-DAIMLER-PUCH | 5081070030 |
| SUZUKI | 1651083010, 1651083001, 1651083000, 1651073013, 1651073012 |
| TALBOT | 75221627 |
| TECAFILTERS | H0616 |
| TECALEMIT | FB5336, FB5309, FB5306 |
| TECFIL | PSL1560, PS966, PS1560 |
| TECNOCAR | R9, R432, R349, R158, OP965, R943, R926, R922 |
| TOWMOTOR | 971450 |
| TOYOTA | 156017600971 |
| UFI FILTERS | 2313102, 2313101, 2313100 |
| UNIPART | GFE246, GFE240, GFE239, GFE236, GFE231, GFE227, GFE209, GFE180, GFE177, GFE173 |
| VAICO | V330004, V400080 |
| VIC | C703A, C703 |
| VOLVO | VOE8614745, VOE861474, 8614745, 861474 |
| WAKO | LO822K |
| WIPAC | CA118 |
| WIX | 51339 |
| WIX FILTERS | 51348, WIX FILTERS, 51348XP |
| WOODGATE | WGL3338 |
| YALE | 440002266 |
BALDWIN B7290 Customer Reviews
No reviews yet
Be the first to review this product!
BALDWIN B7290 Manufacturer Information
Baldwin® is a world-renowned leader in the engine mobile filtration. A brand of Parker Engine Mobile Aftermarket Division (E.M.A.M.), Baldwin Filters provides high-quality filtration products and services for engines and mobile equipment. Since 1936, J.A. Baldwin, the founder of Baldwin Filtration, has recognized the importance of a highly efficient mobile filtration system. It is what inspired him to design an improved lube filter and set off its production in Wisconsin. Currently, Baldwin offers outstanding product quality, a vast distribution network, and one of the industry's most comprehensive product lines. Baldwin's broad range of filtration products and technologies provides customers with a one-stop source for all their engine and mobile filtration needs.
