(888) 312-8812 Login SignupDELPHI AF10374 Mass Air Flow Sensor
$14149
Limited availability at this price!
In Stock
Get it by Monday, Aug 17
DELPHI AF10374 Part Description
Manufacturer
Product Description
Mass Air Flow Sensor
Features & Benefits
- Delphi mass air flow sensors are the global benchmark for accuracy and signal noise
- Delphi mass air flow sensors feature high quality sensing elements for outstanding performance over a wide range of ambient temperatures
- Delphi is a manufacturer of OE mass air flow sensors since their first use over 30 years ago
- All parts are calibrated and tested to match the OE part
- Probe solution offered wherever possible to reduce repair time by eliminating the need to replace the flow tube
- Delphi OE technology validated to match the vehicle applications
DELPHI AF10374 Specifications
Product Attributes
| Package Contents | Mass Air Flow Sensor - Probe Only |
| Item Grade | Standard Replacement |
| Color | Black |
| Housing Included | No |
| Terminal Type | Pin |
| Mounting Hardware Included | No |
| Universal Or Specific Fit | Specific |
| Grade Type | Standard Replacement |
| Connector Quantity | 1 |
| Connector Shape | Rectangle |
| Mounting Hole Quantity | 2 |
| Terminal Quantity | 4 |
| Connector Gender | Female |
| Terminal Gender | Male |
| Wiring Harness Included | No |
| Mounting Type | Bolt-On |
| Mounting Bracket Included | No |
| Sensor Casing Length | 60 MM |
| Sensor Casing Width | 45.8 MM |
| Voltage | 12.0 2H |
| Gasket Or Seal Included | Yes |
| Bolt Hole Center To Bolt Hole Center | 40.40 MM |
| Mounting Hole Diameter | 0.1 IN |
| Seal Outside Diameter | 39 mm |
| Seal Quantity | 1 |
| Sensor Casing Length | 2.3 IN |
| Sensor Casing Width | 1.8 IN |
| Bolt Hole Center To Bolt Hole Center | 1.50 IN |
| Mounting Hole Diameter | 4.5 MM |
| Seal Outside Diameter | 1.5 IN |
| Intake Air Temperature (IAT) Included | Yes |
Additional Information
| Warranty Distance UOM | DH |
| Warranty Distance | 12000 |
| Harmonized Tariff Code (Schedule B) | 9026800000 |
| Warranty Time UOM | MO |
| Warranty Time | 12 |
| Harmonized Tariff Code (HTS) | 9026802000 |
| Country of Origin (Primary) | CN |
| UPC | 00689604286692 |
| VMRS Code | 045021019 |
| UNSPSC | 41111931 |
DELPHI AF10374 Cross References
| Brand | Part Number |
|---|---|
| BWD | MA1168 |
| CARDONE Reman | 74-50091 |
| Ford | CP9Z 12B579-B |
| GLOBAL PARTS DISTRIBUTORS | 1813230 |
| HITACHI | MAF0114 |
| HOLSTEIN | 2MAF0027 |
| Hitachi Automotive | MAF0114 |
| Motorcraft | AFLS-196 |
| N/A | 214175, DL-3109, 5S15672, XTP450091, MF21310 |
| STANDARD IGNITION | MAS0336 |
| Spectra Premium | MA282 |
| Standard Motor Products | MAS0336 |
| VEMO | V25720702 |
DELPHI AF10374 Fits Vehicles
- Ford SSV Plug-In Hybrid (2019-2020)
- Ford Police Responder Hybrid (2019-2020)
- Ford Escape (2017-2019)
- Ford Transit Connect (2016-2022)
- Lincoln MKZ (2013-2020)
- Ford Fusion (2013-2020)
- Ford C-Max (2013-2018)
- Ford Focus (2012-2018)
