(888) 312-8812 Login SignupRAYBESTOS 582034R Raybestos R-Line Brake Rotor
$61.22
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RAYBESTOS 582034R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Rotor
Application Summary
2019-2016 Chevrolet Cruze Rear, 2023-2017 Chevrolet Bolt EV Rear, 2019-2016 Chevrolet Volt Rear, 2023-2022 Chevrolet Bolt EUV Rear
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Low Initial Lateral Runout and Thickness Variation
- R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
- Mill Balanced Edges
- R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
RAYBESTOS 582034R Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.36 IN |
| Center Hole Diameter | 59.95 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 0.315 IN |
| Discard Thickness | 8 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 6.929 IN |
| Inside Diameter | 176 MM |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 4.134 IN |
| Mounting Bolt Hole Circle Diameter | 105 MM |
| Mounting Bolt Hole Diameter | 0.551 IN |
| Mounting Bolt Hole Diameter | 14 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.394 IN |
| Nominal Thickness | 10 MM |
| Outside Diameter | 10.394 IN |
| Outside Diameter | 264 MM |
| Overall Height | 1.732 IN |
| Overall Height | 44 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213218800 |
RAYBESTOS 582034R Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | YH566214P |
| AUTOPARTSOURCE | 593134 |
| AutoZone | 72073DG, 72073DL |
| Autoxtra | AX901604, AX901604P |
| BRAKEBEST | 582034, 582034R |
| BrakeBest | 582034RGS |
| CENTRIC | 120.62151, 121.62151, 126.62151SL, 126.62151SR, 127.62151L, 127.62151R, 128.62151L, 128.62151R, 320.62151 |
| Centric Parts | 120.62151, 121.62151, 126.62151SL, 126.62151SR, 127.62151L, 127.62151R, 128.62151L, 128.62151R, 320.62151 |
| Dura Corp | BR901604, BR901604-01 |
| DuraGo | BR901604, BR901604-01 |
| GM | 13509119, 13514609, 13514611, 13597355 |
| General Motors | 13509119, 13514609, 13514611, 13597355 |
| MAGMA PRODUCTS | PMR223151 |
| NEWTEK AUTOMOTIVE | R1604 |
| Newtek Automotive USA | R1604 |
| PROMAX | 14-650015 |
| Qualis | 41340 |
| TopNotch | TN582034GEO |
| Ultra Brake | 55219 |
| WORLDPAC | 1407-566214, 1427-711333 |
| Wagner Brake | BD180830E |
| Winhere | 6612140 |
RAYBESTOS 582034R Fits Vehicles
- Chevrolet Bolt EUV (2022-2023)
- Chevrolet Bolt EV (2017-2023)
- Chevrolet Cruze (2016-2019)
- Chevrolet Volt (2016-2019)
