DELPHI TC1628 Ball Joint

★★★★★ (0)

MSRP: $56.91

$37.49

Save $19.42

Limited availability at this price!

In Stock

Get as soon as Monday, Nov 30
30-day Return Policy On eligible items Details
Free Ground shipping on orders over $499 details
Orders placed over the weekend will be processed the next business day.

DELPHI TC1628 Part Description

Manufacturer

DELPHI

Product Description

Ball Joint

Features & Benefits

  • Delphi ball joints manufactured with high quality forgings for increased strength and smooth operation
  • Ball joints utilize chloroprene rubber boots which improves durability, preventing premature failure
  • Delphi machines to micron tolerances to guarantee durability and smooth joint operation
  • Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics

DELPHI TC1628 Specifications

Product Attributes

Position(s)Front Lower
Item GradeStandard Replacement
MaterialBall Material - Alloy Steel SAE 5140, Housing Material - Carbon Steel SAE 1040
ColorGray
Stud Thread Diameter0.625 IN
Castle Nut IncludedYes
Grease Fitting IncludedYes
Suspension Grade TypeStandard Replacement
Bushings IncludedNo
Dust Boot IncludedYes
Ball Joint AssemblyYes
Width77 MM
Cotter Pin IncludedYes
Cotter Pin HoleYes
Mounting Hardware IncludedYes
Mounting Bolt Length1.181 IN
Mounting Bolt Length30.00 MM
Washers IncludedYes
Height5.394 IN
Height110.00 MM
Nuts IncludedYes
Mounting Hole Quantity2
AdjustableNo
GreaseableYes
Stud Thread Length1.437 IN
Wrench Size8mm
Stud TypeThreaded
Mounting TypeBolt-In
Distance Between Mounting Holes75.00 MM
Dust Boot MaterialRubber
Mounting Bolt Shank Diameter10.00 MM
Mounting Bolt Head Diameter0.630 IN
Mounting Bolt Head Diameter16.00 MM
Mounting Bolts IncludedYes
Mounting Bolt Thread Pitch1.5 MM
Mounting Bolt Thread Length28.00 MM
Mount Plate IncludedNo
Tapered StudYes
Stud Taper Per Foot0.125 IN
Stud Tapered End 2 Diameter0.752 IN
Stud Tapered End 2 Diameter19.1 MM
Stud Tapered End 1 Diameter0.874 IN
Stud Tapered End 1 Diameter22.2 MM
Stud Threads Per Inch18
Stud Thread Diameter15.88 MM
Stud Thread Length36.5 MM
Mounting Bolt Shank Diameter0.390 IN
Mounting Bolt Thread Length1.100 IN

Additional Information

Harmonized Tariff Code (Schedule B)8708807000
Harmonized Tariff Code (HTS)8708806590
Warranty SpecialLimited
Warranty Special UOMLT
Country of Origin (Primary)TR
UPC00689604277126
VMRS Code016001015
UNSPSC25174203

DELPHI TC1628 Cross References

BrandPart Number
DORMANBJ850075, BJ850075PR
FordC5AZ-3050A, C5AZ-3050B, C7AZ-3050A, C7AZ-3050B, D2AZ-3079A
MAS IndustriesB8059
MOOG Chassis ProductsK8059
MevotechMK8059
N/AB8059PR, GK8059

DELPHI TC1628 Fits Vehicles

  • Ford Country Sedan (1965-1972)
  • Ford Country Squire (1965-1972)
  • Ford Custom (1965-1972)
  • Ford Custom 500 (1965-1972)
  • Ford Galaxie (1965-1967)
  • Ford Galaxie 500 (1965-1972)
  • Ford Gran Torino (1972)
  • Ford LTD (1965-1972)
  • Ford Ranch Wagon (1965-1972)
  • Ford Ranchero (1972)
  • Ford Thunderbird (1967-1972)
  • Ford Torino (1972)
  • Lincoln Continental (1970-1972)
  • Lincoln Mark III (1968-1971)
  • Lincoln Mark IV (1972)
  • Mercury Brougham (1967)
  • Mercury Colony Park (1965-1972)
  • Mercury Marquis (1967-1972)
  • Mercury Montclair (1965-1966)
  • Mercury Montego (1972)
  • Mercury Monterey (1965-1972)
