(888) 312-8812 Login SignupDELPHI FG2035 Fuel Pump Module Assembly
MSRP: $677.82
$55749
Save $120.33
Limited availability at this price!
In Stock
Get it by Friday, Dec 26
DELPHI FG2035 Part Description
DELPHI FG2035 Specifications
Product Attributes
| Package Contents | Fuel Pump Module Assembly w/Float Arm, Seal, Instruction Sheet |
| Fuel Level Sender Assembly Included | Yes |
| System Pressure | 55 psi |
| Item Grade | Standard Replacement |
| Vapor Pressure Sensor | No |
| Outlet Outside Diameter | 0.375 IN |
| Voltage | 12 2H |
| Fuel Type | Gas |
| Regulator Included | Yes |
| Terminal Type | Blade |
| Gasket Or Seal Included | Yes |
| Terminal Quantity | 4 |
| Lock Ring Included | No |
| Terminal Gender | Male |
| Strainer Included | Yes |
| Inlet Type | Strainer |
| Outlet Type | Quick Connect |
| Outlet Quantity | 2 |
| In Tank or External | In Tank |
| Resistance Ohms Empty | 250 82 |
| Resistance Ohms Full | 40 82 |
| Internal Or External Strainer | Internal |
| Pump Type | Electric |
| Average Current Draw | 17 68 |
| Fuel Sending Unit Included | Yes |
| Negative Ground | No |
| Maximum Pressure | 87 PS |
| Mounting Hardware Included | No |
| Grade Type | Premium |
| Connector Quantity | 1 |
| Connector Shape | Rectangle |
| Housing Material | Plastic |
| Installation Warnings | No |
| Connector Gender | Female |
| Fuel Filter Included | Yes |
| Gasket Or Seal Material | Nitrile Rubber |
| Minimum Pressure | 46 PS |
| Wire Harness Included | No |
| Pump Design | Turbine |
| Fuel Tank Pressure Sensor Included | No |
| Average Flow Rating | 29 GPH |
Additional Information
| Country of Origin (Primary) | TH |
| Warranty Special | Limited Lifetime |
| Harmonized Tariff Code (Schedule B) | 8413309000 |
| Harmonized Tariff Code (HTS) | 9026204000 |
| Warranty Special UOM | LF |
| UPC | 00689604280881 |
| VMRS Code | 044003258 |
| UNSPSC | 25172409 |
DELPHI FG2035 Part Interchanges
| Brand | Part Number |
|---|---|
| ACDelco | MU2173, MU2350, SK1472 |
| AutoZone | EFG2035 |
| General Motors | 22966044, 23336547, 23475180, 84240344, 84240352, 84815635, 13510983, 22966043, 23190871 |
DELPHI FG2035 Fits Vehicles
- Chevrolet Corvette (2014-2018)
DELPHI FG2035 Customer Reviews
No reviews yet
Be the first to review this product!
