(888) 312-8812 Login SignupDELPHI AF10416 Mass Air Flow Sensor
MSRP: $291.86
$18099
Save $110.87
Limited availability at this price!
In Stock
Get it by Wednesday, Dec 17
DELPHI AF10416 Part Description
DELPHI AF10416 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Package Contents | Mass Air Flow Sensor - Complete Assembly |
| Color | Black and Silver |
| Housing Included | Yes |
| Inlet Connection Diameter | 3.386 IN |
| Inlet Connection Diameter | 86 MM |
| Outlet Connection Diameter | 3.4 IN |
| Outlet Connection Diameter | 85.6 MM |
| Terminal Type | Blade |
| Mounting Hardware Included | No |
| Universal Or Specific Fit | Specific |
| Grade Type | Regular |
| Connector Quantity | 1 |
| Connector Shape | Oval |
| Mounting Hole Quantity | 2 |
| Housing Material | Plastic |
| Terminal Quantity | 5 |
| Connector Gender | Female |
| Terminal Gender | Male |
| Wiring Harness Included | No |
| Mounting Type | Bolt-On |
| Mounting Bracket Included | No |
| Sensor Casing Length | 100 MM |
| Sensor Casing Width | 105 MM |
| Voltage | 12.0 2H |
| Gasket Or Seal Included | No |
| Bolt Hole Center To Bolt Hole Center | 111.10 MM |
| Mounting Hole Diameter | 0.2 IN |
| Seal Quantity | 0 |
| Sensor Casing Length | 3.9 IN |
| Sensor Casing Width | 4.1 IN |
| Bolt Hole Center To Bolt Hole Center | 4.30 IN |
| Mounting Hole Diameter | 7 MM |
Additional Information
| Warranty Distance UOM | DH |
| Warranty Distance | 12000 |
| Harmonized Tariff Code (Schedule B) | 9026800000 |
| Warranty Time UOM | MO |
| Warranty Time | 12 |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 9026802000 |
| UPC | 00689604282557 |
| VMRS Code | 045021019 |
| UNSPSC | 41111931 |
DELPHI AF10416 Part Interchanges
| Brand | Part Number |
|---|---|
| Bosch | 0280218219 |
| Spectra Premium | MA276 |
| ACDelco | 2134250 |
| BWD | MA1109 |
| General Motors | 15875837 |
| Suzuki | 13800-78J00, 13800-78J01, 1380078J02 |
| CARDONE Reman | 74-10155 |
| Standard Motor Products | MAS0272 |
| NAPA Reman Computers | XTP410155 |
| Blue Streak Electronics New | MF21187N |
| N/A | 214150, 19355502, MQ6214, 86-10160, 74-10160, 245-1087, XTP410160, MF21357, 213-4783 |
DELPHI AF10416 Fits Vehicles
- Chevrolet Traverse (2009-2011)
- Saturn Outlook (2009-2010)
- GMC Acadia (2009-2011)
- Pontiac G8 (2009)
- Pontiac Torrent (2009)
- Chevrolet Equinox (2009)
- Buick Enclave (2009-2011)
- Cadillac STS (2009-2011)
- Cadillac SRX (2009)
- Cadillac CTS (2009-2011)
- Suzuki XL-7 (2007-2009)
