(888) 312-8812 Login SignupDELPHI AF10352 Mass Air Flow Sensor
MSRP: $142.09
$13699
Save $5.10
Limited availability at this price!
In Stock
Get it by Wednesday, Dec 17
DELPHI AF10352 Part Description
DELPHI AF10352 Specifications
Product Attributes
| Package Contents | Mass Air Flow Sensor - Probe Only |
| Item Grade | Standard Replacement |
| Color | Black and Silver |
| Housing Included | No |
| Terminal Type | Blade |
| Mounting Hardware Included | No |
| Universal Or Specific Fit | Specific |
| Grade Type | Regular |
| Connector Quantity | 1 |
| Connector Shape | Oval |
| Mounting Hole Quantity | 2 |
| Terminal Quantity | 4 |
| Connector Gender | Female |
| Terminal Gender | Male |
| Wiring Harness Included | No |
| Mounting Type | Bolt-On |
| Mounting Bracket Included | No |
| Sensor Casing Length | 92 MM |
| Sensor Casing Width | 50.5 MM |
| Voltage | 12.0 2H |
| Gasket Or Seal Included | Yes |
| Bolt Hole Center To Bolt Hole Center | 68.70 MM |
| Mounting Hole Diameter | 0.1 IN |
| Seal Outside Diameter | 16 mm |
| Seal Quantity | 1 |
| Sensor Casing Length | 3.6 IN |
| Sensor Casing Width | 1.9 IN |
| Bolt Hole Center To Bolt Hole Center | 2.70 IN |
| Mounting Hole Diameter | 4.5 MM |
| Seal Outside Diameter | 0.6 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 9026802000 |
| Warranty Distance UOM | DH |
| Warranty Distance | 12000 |
| Harmonized Tariff Code (Schedule B) | 9026800000 |
| Warranty Time UOM | MO |
| Warranty Time | 12 |
| Country of Origin (Primary) | CN |
| UPC | 00689604266960 |
| VMRS Code | 045021019 |
| UNSPSC | 41111931 |
DELPHI AF10352 Part Interchanges
| Brand | Part Number |
|---|---|
| Motorcraft | AFLS-104RM |
| Spectra Premium | MA162 |
| Hitachi Automotive | AFH70-04M, MAF0017 |
| Richporter | MA122 |
| BWD | 29078, MA1008 |
| Duralast | DL-3020 |
| CARDONE New | 86-9508 |
| Ford | F2VZ 12B579-AARM |
| CARDONE Reman | 74-9508 |
| Dorman | 917-832 |
| Standard Motor Products | MAS0123, MF0876 |
| NAPA Reman Computers | MAF69508, XTP49508 |
| Blue Streak Electronics New | MF0876 |
| WAI | MAF10111 |
| N/A | MQ6212, 245-1014, 245-2014, DL-6044 |
DELPHI AF10352 Fits Vehicles
- Mercury Grand Marquis (1992-1994)
- Lincoln Town Car (1993-1994)
- Ford Mustang (1994-1995)
- Ford Crown Victoria (1992-1994)
