WABCO 9254614710 - Air Brake Spring Brake Cylinder Assembly - Tristop Cylinder Disc G-24/30 V
$89649
30 day lead time
Pay over 3-12 months with
. Learn more
. Learn more
WABCO part description
Tristop Cylinder Disc, G-24/30 V
Product Attributes
| Return-Spring Force | 210 N |
| Max. operating pressure | 147.94 / 123.28 psi |
| Weight | 21.605 |
| Push-Rod Length | 15 mm |
| Max. operating pressure | 147.94 / 123.28 psi |
| Size | 222 x 222 x 353 |
| Calculated Volume (dm³) | 17.3973 |
| Stroke | 65/65 mm |
| Type | 24/30 |
| Bolt Lengths | 43.0 mm |
| Output Force M | 8400 N |
| Type Of Operation | Disc |
| Push-rod thread | Ball R8 |
| Temperature Range | -45°C to +80°C |
| Total Length | 274.0 mm |
| Bolt Threads | M16 x 1.5 |
| Opposite | 925 461 470 0 |
| Port thread 11 | M16 x 1.5 JED - 152 |
| Port thread 12 | M12 x 1.5 JED - 152 |
| Release Pressure | 5.3 bar |
| Distance between bolts | 120.6 mm |
| Port threads | M16 x 1.5 |
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
