DELPHI TC2202 Ball Joint

★★★★★ (0)
Delphi TC2202 Suspension Ball Joint Ball Joint
DELPHI
Tap to view 1 more

$38.49

Limited availability at this price!

In Stock

Get as soon as Wednesday, Nov 25
30-day Return Policy On eligible items Details
Free Ground shipping on orders over $499 details

DELPHI TC2202 Part Description

Manufacturer

DELPHI

Product Description

Ball Joint

Features & Benefits

  • Delphi ball joints manufactured with high quality forgings for increased strength and smooth operation
  • Ball joints utilize chloroprene rubber boots which improves durability, preventing premature failure
  • Delphi machines to micron tolerances to guarantee durability and smooth joint operation
  • Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics

DELPHI TC2202 Specifications

Product Attributes

Position(s)Front Upper
Item GradeStandard Replacement
MaterialSteel
Maximum Outside Diameter1.917 IN
Maximum Outside Diameter48.70 MM
ColorGray
Stud Thread Diameter0.5 IN
Stud Thread Diameter12.7 MM
Castle Nut IncludedYes
Grease Fitting IncludedYes
Suspension Grade TypeStandard Replacement
Bushings IncludedNo
Dust Boot IncludedYes
Ball Joint AssemblyYes
Width80.5 MM
Cotter Pin IncludedYes
Cotter Pin HoleYes
Mounting Hardware IncludedYes
Mounting Bolt Length1.161 IN
Mounting Bolt Length29.50 MM
Washers IncludedNo
Height4.138 IN
Height105.10 MM
Nuts IncludedYes
Mounting Hole Quantity4
AdjustableNo
Stud Thread Length0.74 IN
Stud Thread Length18.8 MM
Wrench Size11mm
Stud TypeThreaded
Mounting TypeBolt-In
Distance Between Mounting Holes46.00 MM
Dust Boot MaterialRubber
Mounting Bolt Shank Diameter0.250 IN
Mounting Bolt Shank Diameter6.35 MM
Mounting Bolt Head Diameter0.484 IN
Mounting Bolt Head Diameter12.30 MM
Mounting Bolts IncludedYes
Mounting Bolt Threads Per Inch28
Mounting Bolt Thread Length0.906 IN
Mounting Bolt Thread Length23.00 MM
Mounting Bolt Thread Diameter0.250 IN
Mount Plate IncludedNo
Tapered StudYes
Stud Tapered End 2 Diameter0.661 IN
Stud Tapered End 2 Diameter16.8 MM
Stud Tapered End 1 Diameter0.539 IN
Stud Tapered End 1 Diameter13.7 MM
Stud Threads Per Inch20
Length79.00 MM
Length3.110 IN
Mounting Bolt Thread Diameter6.35 MM

Additional Information

Harmonized Tariff Code (HTS)8708806590
Warranty SpecialLimited
Warranty Special UOMLT
Harmonized Tariff Code (Schedule B)8708807000
Country of Origin (Primary)TR
UPC00689604275115
VMRS Code016001014
UNSPSC25174203

DELPHI TC2202 Cross References

BrandPart Number
Beck/Arnley101-6755
DORMANB5320, B5320XL
General Motors17980952, 19133669, 8191336690
Isuzu8-17980-952-0, 8191336690
MAS IndustriesB5320
MEVOTECHTXK5320
MOOGK5320
MOOG Chassis ProductsK5320
MevotechMK5320
N/A10372887, GK5320, TXK5320, B5320XL, 610.66008
TRWJBJ7035

DELPHI TC2202 Fits Vehicles

  • Chevrolet Blazer (1995-2005)
  • Chevrolet S10 (1983-2004)
  • Chevrolet S10 Blazer (1983-1994)
  • GMC Jimmy (1992-2005)
  • GMC S15 (1984-1990)
  • GMC S15 Jimmy (1984-1991)
  • GMC Sonoma (1991-2004)
  • GMC Syclone (1991)
  • GMC Typhoon (1992-1993)
  • Isuzu Hombre (1998-2000)
  • Oldsmobile Bravada (1991-1994, 1996-2001)
