Delphi TA2535 - Tie Rod End
$1749
MSRP: $22.86
Save: $5.37
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
DELPHI part description
Product Description
Tie Rod End
Product Attributes
| Position(s) | Inner |
| Item Grade | Standard Replacement |
| Color | Black |
| End 1 Gender | Male |
| End 2 Gender | Male |
| Pre-Greased | Yes |
| Dust Boot Included | Yes |
| Width | 43 MM |
| Type | Straight |
| Mounting Hardware Included | Yes |
| End 2 Thread Diameter | 0.687 IN |
| End 2 Thread Diameter | 17.46 MM |
| Height | 80.00 MM |
| Housing Material | Steel |
| Tube Diameter | 0.748 IN |
| Tube Diameter | 19.00 MM |
| Adjustable | No |
| Weight | 1.54 lb |
| Cone Outside Diameter | 15.90 MM |
| Bearing Material | Plastic |
| End 1 Thread Direction | Clockwise (Right) |
| End 2 Thread Direction | Counterclockwise (Left) |
| Stud Type | Threaded |
| Length - Stud Center to End | 8.661 IN |
| Length - Stud Center to End | 220.00 MM |
| Dust Boot Material | Rubber |
| Tie Rod Material | Steel |
| End 2 Threads Per Inch | 18 |
| End 1 Threads Per Inch | 20 |
| End 1 Thread Diameter | 0.500 IN |
| End 1 Thread Diameter | 12.70 MM |
| Shank Length | 15.90 MM |
| Stud Length | 15.90 MM |
| Grade Type | Standard |
| Grade | Premium |
| Shank Length | 0.626 IN |
| Stud Length | 0.626 IN |
| Cone Outside Diameter | 0.626 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708998180 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Harmonized Tariff Code (Schedule B) | 8708998175 |
| Country of Origin (Primary) | TR |
| UPC | 00689604274927 |
| VMRS Code | 015004070 |
| UNSPSC | 25174205 |
Part Interchanges
Fits Vehicles
- GMC Jimmy (1971-1972)
- Chevrolet Blazer (1971-1972)
- Pontiac Parisienne (1971-1974, 1976)
- GMC P15/P1500 Van (1971-1972)
- GMC G15/G1500 Van (1971-1972)
- GMC C15/C1500 Suburban (1971-1972)
- GMC C15/C1500 Pickup (1971-1972)
- Chevrolet Townsman (1971-1972)
- Chevrolet P10 Van (1971-1972)
- Chevrolet Kingswood (1971-1972)
- Chevrolet G10 Van (1971-1972)
- Chevrolet C10 Suburban (1971-1972)
- Chevrolet C10 Pickup (1971-1972)
- Chevrolet Biscayne (1971-1972)
- Chevrolet Brookwood (1971-1972)
- Buick Centurion (1971-1973)
- Pontiac Grand Safari (1971-1976)
- Pontiac Grandville (1971-1975)
- Pontiac Catalina (1971-1976)
- Pontiac Bonneville (1971-1976)
- Oldsmobile Delta 88 (1971-1976)
- Oldsmobile Custom Cruiser (1971-1976)
- Oldsmobile 98 (1971-1976)
- Chevrolet Impala (1971-1976)
- Chevrolet Caprice (1971-1976)
- Chevrolet Bel Air (1971-1975)
- Buick Riviera (1971-1976)
- Buick LeSabre (1971-1976)
- Buick Estate Wagon (1971-1976)
- Buick Electra (1971-1976)
