Item Grade	Standard Replacement
Position(s)	Front Right Lower
Material	Steel
Maximum Outside Diameter	2.224 IN
Maximum Outside Diameter	56.50 MM
Color	Black
Stud Thread Diameter	0.63 IN
Stud Thread Diameter	16 MM
Castle Nut Included	No
Grease Fitting Included	No
Suspension Grade Type	Standard
Bushings Included	No
Dust Boot Included	Yes
Ball Joint Assembly	Yes
Width	98.5 MM
Cotter Pin Included	No
Cotter Pin Hole	No
Mounting Hardware Included	Yes
Mounting Bolt Length	1.890 IN
Mounting Bolt Length	48.00 MM
Washers Included	Yes
Height	3.720 IN
Height	94.50 MM
Nuts Included	Yes
Mounting Hole Quantity	4
Adjustable	No
Greaseable	No
Stud Thread Length	0.787 IN
Stud Thread Length	20 MM
Wrench Size	19mm
Stud Type	Threaded
Mounting Type	Bolt-In
Distance Between Mounting Holes	46.00 MM
Dust Boot Material	Rubber
Mounting Bolt Shank Diameter	0.472 IN
Mounting Bolt Shank Diameter	12.00 MM
Mounting Bolt Head Diameter	0.866 IN
Mounting Bolt Head Diameter	22.00 MM
Mounting Bolts Included	Yes
Mounting Bolt Thread Pitch	1.25 MM
Mounting Bolt Thread Length	1.181 IN
Mounting Bolt Thread Length	30.00 MM
Mounting Bolt Thread Diameter	12.00 MM
Mount Plate Included	No
Tapered Stud	Yes
Stud Tapered End 2 Diameter	0.87 IN
Stud Tapered End 2 Diameter	22.1 MM
Stud Tapered End 1 Diameter	0.766 IN
Stud Tapered End 1 Diameter	19.45 MM
Stud Thread Pitch	1.5 MM
Length	137.00 MM
Length	5.390 IN
Mounting Bolt Thread Diameter	0.470 IN

Harmonized Tariff Code (Schedule B)	8708807000
Country of Origin (Primary)	TR
Harmonized Tariff Code (HTS)	8708806590
Warranty Special	Limited Lifetime
Warranty Special UOM	LF
UPC	00689604260319
VMRS Code	016001015
UNSPSC	25174203

DELPHI TC833 Ball Joint

DELPHI TC833 Part Description
