DELPHI TC519 Part Description
Manufacturer
Product Description
Ball Joint
Features & Benefits
- Delphi ball joints manufactured with high quality forgings for increased strength and smooth operation
- Ball joints utilize chloroprene rubber boots which improves durability, preventing premature failure
- Delphi machines to micron tolerances to guarantee durability and smooth joint operation
- Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
DELPHI TC519 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Lower |
| Material | Steel |
| Maximum Outside Diameter | 2.157 IN |
| Maximum Outside Diameter | 54.80 MM |
| Color | Gray |
| Stud Thread Diameter | 0.63 IN |
| Stud Thread Diameter | 16 MM |
| Castle Nut Included | No |
| Grease Fitting Included | No |
| Suspension Grade Type | Standard Replacement |
| Bushings Included | No |
| Dust Boot Included | Yes |
| Ball Joint Assembly | Yes |
| Width | 54.8 MM |
| Cotter Pin Included | No |
| Cotter Pin Hole | No |
| Mounting Hardware Included | Yes |
| Washers Included | No |
| Height | 4.346 IN |
| Height | 110.40 MM |
| Nuts Included | Yes |
| Mounting Hole Quantity | 0 |
| Adjustable | No |
| Greaseable | No |
| Stud Thread Length | 1.425 IN |
| Stud Thread Length | 36.2 MM |
| Stud Type | Threaded |
| Mounting Type | Press-In |
| Dust Boot Material | Rubber |
| Mount Plate Included | No |
| Tapered Stud | Yes |
| Stud Tapered End 2 Diameter | 0.807 IN |
| Stud Tapered End 2 Diameter | 20.5 MM |
| Stud Tapered End 1 Diameter | 0.705 IN |
| Stud Tapered End 1 Diameter | 17.9 MM |
| Stud Thread Pitch | 1.5 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Country of Origin (Primary) | TR |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604259665 |
| VMRS Code | 016001015 |
| UNSPSC | 25174203 |
DELPHI TC519 Cross References
DELPHI TC519 Fits Vehicles
- Mercedes-Benz 350SD (1991)
- Mercedes-Benz 560SEL (1986-1991)
- Mercedes-Benz 560SEC (1986-1991)
- Mercedes-Benz 500SEC (1984-1985)
- Mercedes-Benz 500SEL (1984-1985)
- Mercedes-Benz 450SE (1973-1976)
- Mercedes-Benz 450SEL (1973-1980)
- Mercedes-Benz 350SDL (1990-1991)
- Mercedes-Benz 420SEL (1986-1991)
- Mercedes-Benz 380SE (1984-1985)
- Mercedes-Benz 380SEC (1982-1983)
- Mercedes-Benz 380SEL (1981-1983)
- Mercedes-Benz 300TD (1979-1985)
- Mercedes-Benz 300SEL (1988-1991)
- Mercedes-Benz 300SE (1988-1991)
- Mercedes-Benz 300SDL (1986-1987)
- Mercedes-Benz 300SD (1979-1985)
- Mercedes-Benz 300D (1977-1985)
- Mercedes-Benz 280SE (1977-1980)
- Mercedes-Benz 280S (1975-1976)
- Mercedes-Benz 300CD (1978-1985)
- Mercedes-Benz 280E (1977-1981)
- Mercedes-Benz 280CE (1978-1981)
- Mercedes-Benz 240D (1977-1983)
- Mercedes-Benz 230 (1976-1978)
