Delphi TC294 - Ball Joint
$1949
MSRP: $23.55
Save: $4.06
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
DELPHI part description
Product Description
Ball Joint
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Lower |
| Material | Steel |
| Maximum Outside Diameter | 2.480 IN |
| Maximum Outside Diameter | 63.00 MM |
| Color | Gray |
| Stud Thread Diameter | 0.709 IN |
| Stud Thread Diameter | 18 MM |
| Castle Nut Included | No |
| Grease Fitting Included | No |
| Suspension Grade Type | Standard |
| Bushings Included | No |
| Dust Boot Included | Yes |
| Ball Joint Assembly | Yes |
| Width | 63 MM |
| Cotter Pin Included | No |
| Cotter Pin Hole | No |
| Mounting Hardware Included | Yes |
| Washers Included | No |
| Height | 4.409 IN |
| Height | 112.00 MM |
| Nuts Included | Yes |
| Mounting Hole Quantity | 0 |
| Adjustable | No |
| Greaseable | No |
| Stud Thread Length | 1.299 IN |
| Stud Thread Length | 33 MM |
| Wrench Size | 27mm |
| Stud Type | Threaded |
| Dust Boot Material | Rubber |
| Mounting Bolts Included | No |
| Mount Plate Included | No |
| Tapered Stud | Yes |
| Stud Tapered End 2 Diameter | 0.886 IN |
| Stud Tapered End 2 Diameter | 22.5 MM |
| Stud Tapered End 1 Diameter | 0.776 IN |
| Stud Tapered End 1 Diameter | 19.7 MM |
| Stud Thread Pitch | 1.5 MM |
| Length | 63.00 MM |
| Length | 2.480 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Country of Origin (Primary) | TR |
| UPC | 00689604259054 |
| VMRS Code | 016001015 |
| UNSPSC | 25174203 |
Part Interchanges
Fits Vehicles
- Volkswagen Transporter (1985-1991)
- Volkswagen Vanagon (1980-1991)
