(888) 312-8812 Login SignupDELPHI TC2589 Control Arm and Ball Joint Assembly
Tap to view 2 more
MSRP: $656.92
$29099
Save $365.93
Limited availability at this price!
In Stock
Get it by Thursday, Feb 12
DELPHI TC2589 Part Description
Manufacturer
Product Description
Control Arm and Ball Joint Assembly
Features & Benefits
- Delphi control arms undergo 100% crack detection and ultrasonic flaw detection to ensure materials match OE specifications
- Delphi machines the ball studs to micron tolerances to guarantee durability and smooth joint operation
- Control arms utilize robot welding for consistent performance and quality
- Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
DELPHI TC2589 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Left Lower |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Bushings Included | Yes |
| Ball Joint Stud Type | Threaded |
| Control Arm Construction | Casting/Forged |
| Control Arm Material | Aluminum |
| Mounting Hardware Included | Yes |
| Mounting Hole Quantity | 3 |
| Adjustable | No |
| Greaseable | No |
| Control Arm Maximum Width | 16.339 IN |
| Control Arm Maximum Width | 415.00 MM |
| Control Arm Color | Gray |
| Ball Joint Stud Length | 3.701 IN |
| Ball Joint Stud Length | 94.00 MM |
| Control Arm Maximum Length | 18.583 IN |
| Control Arm Maximum Length | 472.00 MM |
| Mounting Hole Diameter | 0.555 IN |
| Mounting Hole Diameter | 14.10 MM |
| Bushing Material | Rubber |
| Thread Direction | Clockwise (Right) |
| Bushing Color | Black |
| Finish | Uncoated |
| Dust Boot Included | Yes |
| Ball Joint Included | Yes |
| Grade Type | Premium |
| Boot Material | Chloroprene Rubber (CR) |
| Locking Nut Included | Yes |
| Boot Color | Black |
| Steering Type | Power |
| Bearing Material | Plastic |
| Dust Boot Material | Chloroprene Rubber (CR) |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Country of Origin (Primary) | TR |
| UPC | 00689604258149 |
| VMRS Code | 016001001 |
| UNSPSC | 25172013 |
DELPHI TC2589 Cross References
| Brand | Part Number |
|---|---|
| Audi | 7L8 407 151 D, 7L8 407 151 E, 7L8 407 151 F, 7L8 407 151 K |
| Beck/Arnley | 101-6145, 102-6145, 102-7567 |
| CORTECO | 49398558 |
| DORMAN | 521-955, CB12103, CB12103PR |
| Dorman | 52-1955 |
| MAS Industries | CB12103, CB12103PR |
| MEYLE | 116 050 0096, 1160500096S, 116 050 0190 S, 116 050 0191 S |
| MOOG Chassis Products | K620456, RK620147, RK620456, 102-7567 |
| Mevotech | CMS70124 |
| N/A | GS70124, CK620456 |
| TRW | JTC2315 |
| VAICO | V10-0892 |
DELPHI TC2589 Fits Vehicles
- Volkswagen Touareg (2007-2008)
- Audi Q7 (2007-2010)
