DELPHI part description

Product Description

Ball Joint

Product Attributes

Position(s) Front Upper
Item Grade Standard Replacement
Material Steel
Maximum Outside Diameter 1.969 IN
Maximum Outside Diameter 50.0 MM
Color Black
Stud Thread Diameter 0.394 IN
Stud Thread Diameter 10.0 MM
Castle Nut Included No
Grease Fitting Included No
Suspension Grade Type Standard
Bushings Included No
Dust Boot Included Yes
Ball Joint Assembly Yes
Width 85.0 MM
Cotter Pin Included No
Cotter Pin Hole No
Mounting Hardware Included Yes
3068 1.181 IN
Mounting Bolt Length 30.0 MM
Washers Included No
Height 34.331 IN
Nuts Included Yes
Mounting Hole Quantity 3
Adjustable No
Greasable No
4966 2.008 IN
Bushing Material Natural Rubber (NR)
Stud Type Threaded
Mounting Type Bolt On
Distance Between Mounting Holes 50.2 MM
Dust Boot Material Choloroprene Rubber (CR)
Mounting Bolt Shank Diameter 8.0 MM
Mounting Bolts Included Yes
Mounting Bolt Thread Pitch 1.0 MM
9207 0.866 IN
Mounting Bolt Thread Length 22.0 MM
Length 100.0 MM

Additional Information

Harmonized Tariff Code (Schedule B) 8708807000
Country of Origin (Primary) TR
Harmonized Tariff Code (HTS) 8708806590
Warranty Special Limited Lifetime
Warranty Special UOM LF
UPC 00689604254974
VMRS Code 016001014
UNSPSC 25174203

Part Interchanges

Fits Vehicles

  • Mercedes-Benz E280 (2007)
  • Mercedes-Benz SL63 AMG (2009, 2011-2012)
  • Mercedes-Benz E550 (2007-2009)
  • Mercedes-Benz CLS550 (2007-2011)
  • Mercedes-Benz CLS63 AMG (2007-2011)
  • Mercedes-Benz E63 AMG (2007-2009)
  • Mercedes-Benz SL550 (2007-2013)
  • Mercedes-Benz E350 (2006-2009)
  • Mercedes-Benz CLS55 AMG (2006)
  • Mercedes-Benz CLS500 (2006)
  • Mercedes-Benz SL65 AMG (2005-2011)
  • Mercedes-Benz E55 AMG (2003-2006)
  • Mercedes-Benz SL600 (2001-2002, 2004-2011)
  • Mercedes-Benz SL55 AMG (2003-2008)
  • Mercedes-Benz SL500 (2001-2006)
  • Mercedes-Benz E500 (2003-2006)
  • Mercedes-Benz E320 (2002-2009)
