DELPHI TC1188 Part Description
DELPHI TC1188 Specifications
Product Attributes
| Position(s) | Front Lower |
| Item Grade | Standard Replacement |
| Material | Steel |
| Maximum Outside Diameter | 3.937 IN |
| Maximum Outside Diameter | 100.00 MM |
| Castle Nut Included | Yes |
| Grease Fitting Included | No |
| Suspension Grade Type | Standard |
| Bushings Included | No |
| Dust Boot Included | Yes |
| Ball Joint Assembly | Yes |
| Width | 100 MM |
| Type | Premium |
| Cotter Pin Included | Yes |
| Cotter Pin Hole | Yes |
| Mounting Hardware Included | Yes |
| Mounting Bolt Length | 1.476 IN |
| Mounting Bolt Length | 37.50 MM |
| Washers Included | Yes |
| Height | 3.150 IN |
| Height | 80.00 MM |
| Nuts Included | Yes |
| Mounting Hole Quantity | 3 |
| Adjustable | No |
| Greaseable | No |
| Stud Thread Length | 0.827 IN |
| Stud Thread Length | 21 MM |
| Stud Type | Threaded |
| Mounting Type | Bolt-In |
| Distance Between Mounting Holes | 55.90 MM |
| Dust Boot Material | Rubber |
| Bushing Quantity | 0 |
| Mounting Bolt Head Diameter | 21.90 MM |
| Mounting Bolts Included | Yes |
| Mounting Bolt Thread Pitch | 1.25 MM |
| Mounting Bolt Thread Length | 30.00 MM |
| Mount Plate Included | No |
| Tapered Stud | Yes |
| Stud Tapered End 2 Diameter | 0.709 IN |
| Stud Tapered End 2 Diameter | 18 MM |
| Stud Tapered End 1 Diameter | 0.787 IN |
| Stud Tapered End 1 Diameter | 20 MM |
| Stud Thread Pitch | 1.5 MM |
| Length | 123.00 MM |
| Length | 4.840 IN |
| Mounting Bolt Head Diameter | 0.860 IN |
| Mounting Bolt Thread Length | 1.180 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Country of Origin (Primary) | TR |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604271483 |
| VMRS Code | 016001015 |
| UNSPSC | 25174203 |
DELPHI TC1188 Part Interchanges
| Brand | Part Number |
|---|---|
| Beck/Arnley | 101-4147, 101-4879 |
| MOOG Chassis Products | K9645 |
| Mevotech | MK9645 |
| Toyota | 43330-39295 |
| MAS Industries | B9645 |
| Import Direct | BJ11006 |
| TRW | JBJ332 |
| N/A | GK9645, B9645PR |
DELPHI TC1188 Fits Vehicles
- Toyota Pickup (1989-1995)
