(888) 312-8812 Login SignupDELPHI TA1252 Tie Rod End
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
DELPHI TA1252 Part Description
DELPHI TA1252 Specifications
Product Attributes
| Position(s) | Right |
| Item Grade | Standard Replacement |
| Color | Black |
| End 2 Gender | Female |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Dust Boot Included | Yes |
| Width | 42.2 MM |
| Type | Bent |
| Mounting Hardware Included | Yes |
| End 2 Thread Diameter | 0.551 IN |
| End 2 Thread Diameter | 14.00 MM |
| Height | 72.50 MM |
| Housing Material | Steel |
| Tube Diameter | 0.807 IN |
| Tube Diameter | 20.50 MM |
| Adjustable | No |
| Greaseable | No |
| Weight | 0.82 lb |
| Cone Outside Diameter | 16.15 MM |
| Bearing Material | Plastic |
| End 1 Thread Direction | Clockwise (Right) |
| End 2 Thread Direction | Clockwise (Right) |
| Stud Type | Threaded |
| End 2 Thread Pitch | 2 MM |
| Length - Stud Center to End | 2.953 IN |
| Length - Stud Center to End | 75.00 MM |
| Dust Boot Material | Rubber |
| Tie Rod Material | Steel |
| End 1 Thread Diameter | 0.394 IN |
| End 1 Thread Diameter | 10.00 MM |
| Shank Length | 16.15 MM |
| Stud Length | 16.15 MM |
| Grade Type | Standard |
| Grade | Premium |
| Shank Length | 0.636 IN |
| Stud Length | 0.636 IN |
| Cone Outside Diameter | 0.636 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708998180 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Harmonized Tariff Code (Schedule B) | 8708998175 |
| Country of Origin (Primary) | TR |
| UPC | 00689604245057 |
| VMRS Code | 015004019 |
| UNSPSC | 25174205 |
DELPHI TA1252 Cross References
| Brand | Part Number |
|---|---|
| Beck/Arnley | 1015546 |
| CORTECO | 49400374 |
| DORMAN | TO86415, TO86415XL |
| Ford | 1015546, 5024332, 6555936, 7243565, 91AX3270AA, 95AB3289AA, 95AX3270AA |
| MOOG Chassis Products | K90490 |
| Mevotech | MES3048RL |
| N/A | ES3048RL, GES3048RL, TO86415XL, JTE7028, TO86415, 91AB3289A2C |
| TRW | JBJ974 |
DELPHI TA1252 Fits Vehicles
- Ford Escort (1991-1997)
