(888) 312-8812 Login SignupDELPHI FG1860 Fuel Pump Module Assembly
$58199
Limited availability at this price!
In Stock
Get it by Tuesday, Feb 3
DELPHI FG1860 Part Description
Manufacturer
Product Description
Fuel Pump Module Assembly
Features & Benefits
- Delphi is a global OE manufacturer and all fuel pumps are built to Delphi's OE standards
- Empty float height and float retention matches OE specifications and guarantees correct gas gauge reading
- Lower amperage draws less load on vehicle's electrical system
- Part is validated, tested and matched to the right vehicle application
- Always be sure to check and clean fuel tank to avoid unnecessary returns
- Lower failure rates due to its innovative design and durability
DELPHI FG1860 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Fuel Level Sender Assembly Included | Yes |
| Fuel Type | Gas/Flex |
| System Pressure | 58 psi |
| Package Contents | Fuel Pump Module Assembly w/Float Arm, Seal, Instruction Sheet |
| Vapor Pressure Sensor | No |
| Outlet Outside Diameter | 0.313 IN |
| Voltage | 12 2H |
| Regulator Included | Yes |
| Maximum Pressure | 62 PS |
| Terminal Type | Blade |
| Gasket Or Seal Included | Yes |
| Terminal Quantity | 4 |
| Lock Ring Included | No |
| Terminal Gender | Male |
| Strainer Included | Yes |
| Inlet Type | Strainer |
| Outlet Type | Quick Connect |
| Outlet Quantity | 3 |
| In Tank or External | In Tank |
| Resistance Ohms Empty | 990 82 |
| Resistance Ohms Full | 50 82 |
| Internal Or External Strainer | Internal |
| Pump Type | Electric |
| Average Current Draw | 13 68 |
| Average Flow Rating | 37 GPH |
| Fuel Sending Unit Included | Yes |
| Negative Ground | No |
| Fuel Type | Gas |
| Mounting Hardware Included | No |
| Grade Type | Premium |
| Connector Quantity | 1 |
| Connector Shape | Rectangle |
| Housing Material | Plastic |
| Installation Warnings | No |
| Connector Gender | Female |
| Fuel Filter Included | Yes |
| Gasket Or Seal Material | Nitrile Rubber |
| Minimum Pressure | 55 PS |
| Wire Harness Included | No |
| Pump Design | Turbine |
| Fuel Tank Pressure Sensor Included | No |
| Universal Or Specific Fit | Specific |
Additional Information
| Harmonized Tariff Code (HTS) | 8413309030 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Harmonized Tariff Code (Schedule B) | 8413309000 |
| Country of Origin (Primary) | CN |
| UPC | 00689604264966 |
| VMRS Code | 044003258 |
| UNSPSC | 25172409 |
DELPHI FG1860 Cross References
| Brand | Part Number |
|---|---|
| AutoZone | DFG1860 |
| Carter | P77011M |
| Chrysler | 6818 7986AB, 6821 7187AB, 68217187AA, 68217187AC, 68217187AD |
| N/A | 6865 6897AA, 4011474 |
| Precision Fuel | A30477 |
| Spectra Premium | SP7224M, SP7253M |
DELPHI FG1860 Fits Vehicles
- Chrysler 200 (2015-2017)
- Jeep Cherokee (2014-2022)
