RAYBESTOS 66670FZN Raybestos Element3 Coated Brake Rotor

★★★★★ (0)
Raybestos 66670FZN Disc Brake Rotor Raybestos Element3 Coated Brake Rotor
RAYBESTOS

MSRP: $105.51

$96.99

Save $8.52

Limited availability at this price!

In Stock

Get it by Friday, Jul 24
No Hassle Return Policy Details
Free Economy shipping on orders over $499 details

RAYBESTOS 66670FZN Part Description

Manufacturer

RAYBESTOS

Product Description

Raybestos Element3 Coated Brake Rotor

Application Summary

2000-1997 Ford F-150 Rear, 2002-1997 Ford Expedition Rear, 2002-1998 Lincoln Navigator Rear

Features & Benefits

  • Grey Fusion 4.0® Coating
  • Grey Fusion 4.0(R) Coating
  • Grey Fusion 4.0® coating provides optimal corrosion resistance and faster brake jobs.
  • Grey Fusion 4.0(R) coating provides optimal corrosion resistance and faster brake jobs.
  • RPT® Rust Prevention Technology
  • RPT(R) Rust Prevention Technology
  • RPT® Rust Prevention Technology for long lasting rust prevention.
  • RPT(R) Rust Prevention Technology for long lasting rust prevention.
  • Cooling Vanes
  • Cooling vanes are coated to ensure vanes remain clear of rust and corrosion for optimal airflow and cooling.
  • OE Matched
  • OE Matched precision and performance.
  • Non-Directional Finish
  • A non-directional ground finish provides a product that is ready to install right out of the box.

RAYBESTOS 66670FZN Specifications

Product Attributes

ABS Tone Ring Included No
Center Hole Diameter 3.44 IN
Center Hole Diameter 87.4 MM
Conventional Or Drum-In-Hat Type Rotor Drum-In-Hat
Directional or Non-Directional Brake Surface Non-Directional
Discard Thickness 0.472 IN
Discard Thickness 12 MM
Harmonize Code 8708.30.5030
Material Cast Iron
Mounting Bolt Hole Circle Diameter 5.315 IN
Mounting Bolt Hole Circle Diameter 135 MM
Mounting Bolt Hole Diameter 0.56 IN
Mounting Bolt Hole Diameter 14.2 MM
Mounting Bolt Hole Quantity 5
Nominal Thickness 0.556 IN
Nominal Thickness 14.1 MM
Outside Diameter 13.15 IN
Outside Diameter 334 MM
Overall Height 2.21 IN
Overall Height 56.15 MM
Salability Restrictions No
Solid Or Vented Type Rotor Solid
Stud/Lug Hole Quantity 5
UNSPSC Code 25171715

Additional Information

Country of Origin (Primary) CN
Canadian Harmonizing Tariff Code 8708309990
Harmonized Tariff Code (HTS) 8708305030
UPC 00887213228106

RAYBESTOS 66670FZN Cross References

BrandPart Number
ADVANCE AUTO PARTS145140, YH145140, YH145140C, YH145140P
AMERICAN REMANUFACTURED789-42059, 89-42059, 89-42085
AUTOSPECIALTYAR8559, AR8559E
AUTOXTRAAX54090
AUTOZONE54047DL, 54047, 54047B, 54047DG, DL54047
AutoxtraAX54090P
BENDIX145140
BOSCHRBR54047
BRAKE HEADQUARTERSBR54702
BRAKEBEST20010330, 66670, 66670FZN, 66670R, 66670RGS
BREMBO08.8445.85, 27168
Brembo08.8445.80
Bridgestone7005023
CALIFORNIA DRUM & ROTOR125526
CENTRIC120.65059, 121.65059, 125.65059, 126.65059CSL, 126.65059CSR, 126.65059SL, 126.65059SR, 127.65059L, 127.65059R, 128.65059CL, 128.65059CR, 128.65059L, 128.65059R, 227.65059L, 227.65059R, 320.65059, 320.65059F, 321.65059
CONTINENTAL-CONTITECHCW14702
Casting Numbers325218, 540471
Centric Parts120.65059, 121.65059, 125.65059, 126.65059CSL, 126.65059CSR, 126.65059SL, 126.65059SR, 127.65059L, 127.65059R, 128.65059CL, 128.65059CR, 128.65059L, 128.65059R, 227.65059L, 227.65059R, 320.65059, 320.65059F, 321.65059
DELPHIRB585
DURA CORPBR54047
Dura CorpBR54090
DuraGoBR54047, BR54090
FORDF75Z2C026BC, XL3Z2C026DA, XL1Z2C026AA
FORMULA BLUE HYDRAULIC BRAKE PARTSE12570064
GREN649501
GUARDIAN52-125526
MIDASBR2048
MIGHTY DISTRIBUTING SYSTEM54047
MOTORCRAFTBRR65
NEWTEK AUTOMOTIVE54047
Newtek Automotive USA54047
PARTS MASTERP125526
POWERSTOPAR8559EVC
PROMAX14-54047
QUALIS54047
QUALITEE INTERNATIONAL64-92-310
QUALITY BRAND54047, Q4129
STANDARD ROTORS AND DRUMS54047
THE UNIVERSAL GROUP102561
TRUSTAR492310, R92310
TopNotchTN66670GEO
UAP54047
Ultra Brake54211
Universal102561
VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURINGX51204
WAGNER BRAKEBD125526
WINHERE661185, YH1185
WORLDPAC1407-25649

RAYBESTOS 66670FZN Fits Vehicles

  • Lincoln Navigator (1998-2002)
  • Ford F-150 (1997-2003)
  • Ford Expedition (1997-2002)
