(888) 312-8812 Login SignupCENTRIC 320.42088 Centric GCX Rotor with Partial Coating
Tap to view 4 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 320.42088 Part Description
Manufacturer
Product Description
Centric GCX Rotor with Partial Coating
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron FormulationEnhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
CENTRIC 320.42088 Specifications
Product Attributes
| Product Grade [cntrc] | Premium |
| Weight [cntrc] Kgs | 5.820 |
| Misc Holes [cntrc] | 1 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Hat Id [cntrc] In | 6.772 |
| Hat Id [cntrc] Mm | 172.000 |
| Disc Mounting [cntrc] | Floating / DIH |
| Vane Style [cntrc] | Straight |
| Weight [cntrc] Lbs | 12.800 |
| Discard Thickness | 14.000 MM |
| Discard Thickness | 0.551 IN |
| Nominal Thickness | 0.630 IN |
| Nominal Thickness | 16.000 MM |
| Disc Finish | Partially Coated |
| Hat Finish | Coated |
| Overall Height | 62.200 MM |
| Overall Height | 2.449 IN |
| Outside Diameter | 307.700 MM |
| Outside Diameter | 12.114 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 172.000 MM |
| Nominal Drum Diameter | 6.772 IN |
| Bearings Included | No |
| Center Hole Diameter | 2.677 IN |
| Center Hole Diameter | 68.000 MM |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 12.700 MM |
| Stud/Lug Hole Diameter | 0.500 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590250848 |
CENTRIC 320.42088 Part Interchanges
| Brand | Part Number |
|---|---|
| Raybestos Brakes | 980333, 980333FZN, 980333R |
| N/A | 90067055, HC31387X, 980710FZN |
CENTRIC 320.42088 Cross References
We have 3 alternatives for the 320.42088 by CENTRIC:
