CENTRIC 320.33054 Part Description
Manufacturer
Product Description
Centric GCX Rotor with Partial Coating
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron FormulationEnhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
CENTRIC 320.33054 Specifications
Product Attributes
| Disc Mounting [cntrc] | Floating |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Lbs | 13.800 |
| Vane Style [cntrc] | Straight |
| Product Grade [cntrc] | Premium |
| Weight [cntrc] Kgs | 6.270 |
| Misc Holes [cntrc] | 1 |
| Discard Thickness | 0.748 IN |
| Discard Thickness | 19.000 MM |
| Nominal Thickness | 22.000 MM |
| Nominal Thickness | 0.862 IN |
| Disc Finish | Partially Coated |
| Hat Finish | Coated |
| Overall Height | 36.700 MM |
| Overall Height | 1.445 IN |
| Outside Diameter | 279.700 MM |
| Outside Diameter | 11.012 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 65.000 MM |
| Center Hole Diameter | 2.559 IN |
| Mounting Bolt Hole Circle Diameter | 100.000 MM |
| Mounting Bolt Hole Circle Diameter | 3.937 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 15.800 MM |
| Stud/Lug Hole Diameter | 0.622 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00889590250091 |
CENTRIC 320.33054 Part Interchanges
| Brand | Part Number |
|---|---|
| N/A | 90074016, HC34143X, 96778FZN |
