(888) 312-8812 Login SignupRAYBESTOS 680686PER Raybestos Specialty - Street Performance S-Groove Brake Rotor
$107.31
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RAYBESTOS 680686PER Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance S-Groove Brake Rotor
Application Summary
2019-2011 Ford Explorer Rear, 2014-2011 Ford Edge Rear, 2019-2009 Ford Taurus Rear, 2019-2009 Ford Flex Rear, 2015-2011 Lincoln MKX Rear, 2012-2009 Lincoln MKS Rear, 2019-2010 Lincoln MKT Rear, 2009 Ford Taurus X Rear
RAYBESTOS 680686PER Specifications
Product Attributes
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.4 IN |
| Discard Thickness | 9.9 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 4.5 IN |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Nominal Thickness | 0.4 IN |
| Nominal Thickness | 10.9 MM |
| Salability Restrictions | No |
| UNSPSC Code | 25171715 |
| Bearings Included | No |
| Center Hole Diameter | 2.7 IN |
| Mounting Bolt Hole Diameter | 0.6 IN |
| Stud/Lug Hole Quantity | 5 |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Weight [cntrc] Kgs | 6.6 |
| Weight [cntrc] Lbs | 14.5 |
| Mounting Bolt Hole Quantity | 5 |
| Surface Type | Smooth |
| Material | Cast Iron |
| Maximum Brake Diameter (Discard) | 330.0 MM |
| Construction | Full Cast |
| Rust Resistant Coating | Yes |
| Inside Diameter | 8.9 IN |
| Overall Height | 1.5 IN |
| Outside Diameter | 8.7 IN |
| Grade Type | Regular |
| ABS Tone Ring Included | No |
| Solid Or Vented Type Rotor | Solid |
| Center Hole Diameter | 68.0 MM |
| Inside Diameter | 225.5 MM |
| Mounting Bolt Hole Diameter | 14.2 MM |
| Outside Diameter | 221.0 MM |
| Overall Height | 38.7 MM |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| Canadian Harmonizing Tariff Code | 8708309990 |
| UPC | 00887213209853 |
RAYBESTOS 680686PER Cross References
| Brand | Part Number |
|---|---|
| AUTOXTRA | AX900928 |
| Advance Auto Parts | G09289SD |
| AutoZone | 42262, 42262DG, 42266 |
| Autoxtra | AX900928P |
| BENDIX | PRT5898 |
| BOSCH | 20010394 |
| BrakeBest | 20010394, 680686, 680686FZN, 680686PER, 680686R, 680686RGS |
| Brembo | 08.B584.10 |
| Centric Parts | 120.61081, 121.61081 |
| DURA CORP | BR900928-02 |
| Dura Corp | BR54165, BR900928 |
| DuraGo | BR900928, BR900928-01 |
| Eurorotor | 54219 |
| FORD | 8G1Z2C026B, BT4Z2C026A, BT4Z2C026B, AG1Z2C026A |
| Ford | 5U2Z1V125GD |
| Newtek Automotive USA | 54165 |
| Parts Master | 900928 |
| TopNotch | TN680686GEO |
| WORLDPAC | 1407-26921 |
| Winhere | 661815 |
RAYBESTOS 680686PER Fits Vehicles
- Lincoln MKX (2011-2015)
- Ford Explorer (2011-2019)
- Ford Edge (2011-2014)
- Lincoln MKT (2010-2019)
- Mercury Sable (2009)
- Ford Taurus (2009-2019)
- Ford Taurus X (2009)
- Ford Flex (2009-2019)
- Lincoln MKS (2009-2012)
