(888) 312-8812 Login SignupRAYBESTOS 981788 Raybestos Specialty - Street Performance Coated Brake Rotor
$39.98
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RAYBESTOS 981788 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Coated Brake Rotor
Application Summary
2016-2013 Fiat 500 Rear, 2017-2015 Ram 700 Rear
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes:Black fusion coating on the rotor hatGrey Fusion 4.0® coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 981788 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.323 IN |
| Center Hole Diameter | 59 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.354 IN |
| Discard Thickness | 9 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 5.949 IN |
| Inside Diameter | 151.1 MM |
| Mounting Bolt Hole Circle Diameter | 3.858 IN |
| Mounting Bolt Hole Circle Diameter | 98 MM |
| Mounting Bolt Hole Diameter | 0.52 IN |
| Mounting Bolt Hole Diameter | 13.2 MM |
| Mounting Bolt Hole Quantity | 4 |
| Nominal Thickness | 0.394 IN |
| Nominal Thickness | 10 MM |
| Outside Diameter | 9.89 IN |
| Outside Diameter | 251.2 MM |
| Overall Height | 1.602 IN |
| Overall Height | 40.7 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 4 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213190328 |
RAYBESTOS 981788 Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | YH324570, YH324570C |
| ATE BRAKE PRODUCTS | SP00019 |
| Advance Auto Parts | YH527276 |
| AutoZone | 72134DL |
| BRAKEBEST | 91925RGS, 981788, 981788R |
| CENTRIC | 120.04005, 121.04005, 126.04005SL, 126.04005SR, 127.04005L, 127.04005R, 128.04005CL, 128.04005CR, 128.04005L, 128.04005R |
| Centric Parts | 120.04005, 121.04005, 126.04005SL, 126.04005SR, 127.04005L, 127.04005R, 128.04005CL, 128.04005CR, 128.04005L, 128.04005R |
| FIAT | 51805559, 68137324AA |
| MAGMA PRODUCTS | PSR143079 |
| NAPA BRAKES | SDK6603 |
| POWERSTOP | EBR1405EVC |
| Qualis | 45879 |
| WORLDPAC | 1427-587157 |
RAYBESTOS 981788 Fits Vehicles
- Ram 700 (2015-2017)
- Fiat 500 (2013-2019)
