WEATHERHEAD part description

Abrasion Resistance Standard
Application Hydraulic systems with petroleum and water-glycol based fluids, for lubricating oils and water.
Bend Radius Min 5.91 inch
Burst Pressure 6000 psi
Color Black
Conductivity Conductive
Construction 1 Ply Braid
Cover Material WeatherSHIELD, Synthetic rubber
Dash Size -16
Impulse Cycle Life 400000 cycle
InsIDe Diameter 1 inch
Lay Line Style Transfer Tape
Length Configuration 50, 250
OutsIDe Diameter 1.37 inch
Package Form Box
Qualified Hose Fittings Z
Reinforcement Material Wire
Tube Material Nitrile
Working Pressure 1500 psi
Working Temperature Max 258.8 degree Fahrenheit
Working Temperature Min -50.8 degree Fahrenheit

Features & Benefits

  • Maximum durability under harsh operating conditions
  • Robust construction able to withstand highest pressures
  • System engineered to extend hose assembly life

Officially acquired by Eaton in 2002, Weatherhead® is one of the industry’s biggest suppliers of hydraulic hose, hose ends, tube fittings, couplings, assembly equipment, and support accessories. Weatherhead crafts top-products that are widely used in mining, agriculture, construction, truck, and bus applications. Eaton delivers Weatherhead thermoplastic tubing in different sizes—from 1/8 to 1 inch—designed for use in air tools, robotics, beverage dispensing as well as air and water supply. Driven by the company’s goal to offer unique solutions to a wide range of markets that enable businesses to be at the forefront of change, Weatherhead remains the truck industry’s leading source of premium-quality hoses, fittings, and adapters for your fleet’s hose and fittings needs
