(888) 312-8812 Login SignupRAYBESTOS 980087FZN Raybestos Element3 Coated Brake Rotor
$61.92
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RAYBESTOS 980087FZN Part Description
Manufacturer
Product Description
Raybestos Element3 Coated Brake Rotor
Application Summary
2015-2005 Hyundai Tucson Rear, 2016-2005 Kia Sportage Rear, 2006-2001 Hyundai Santa Fe Rear
Features & Benefits
- Grey Fusion 4.0® Coating
- Grey Fusion 4.0(R) Coating
- Grey Fusion 4.0® coating provides optimal corrosion resistance and faster brake jobs.
- Grey Fusion 4.0(R) coating provides optimal corrosion resistance and faster brake jobs.
- RPT® Rust Prevention Technology
- RPT(R) Rust Prevention Technology
- RPT® Rust Prevention Technology for long lasting rust prevention.
- RPT(R) Rust Prevention Technology for long lasting rust prevention.
- Cooling Vanes
- Cooling vanes are coated to ensure vanes remain clear of rust and corrosion for optimal airflow and cooling.
- OE Matched
- OE Matched precision and performance.
- Non-Directional Finish
- A non-directional ground finish provides a product that is ready to install right out of the box.
RAYBESTOS 980087FZN Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.99 IN |
| Center Hole Diameter | 75.95 MM |
| Conventional Or Drum-In-Hat Type Rotor | Drum-In-Hat |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 0.331 IN |
| Discard Thickness | 8.4 MM |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 4.5 IN |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Mounting Bolt Hole Diameter | 0.491 IN |
| Mounting Bolt Hole Diameter | 12.45 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.394 IN |
| Nominal Thickness | 10 MM |
| Outside Diameter | 11.181 IN |
| Outside Diameter | 284 MM |
| Overall Height | 2.4 IN |
| Overall Height | 60.95 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213092189 |
RAYBESTOS 980087FZN Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | 145534, YH145534, YH145534C, YH145534P |
| AUTOPARTSOURCE | 582140 |
| AUTOSPECIALTY | JBR958, JBR958E |
| AUTOXTRA | 80980087, AX31336 |
| AUTOZONE | 31336, 31336DG |
| Autoxtra | AX31336P |
| BECK/ARNLEY | 083-2907 |
| BENDIX | 145534 |
| BRAKEBEST | 980087, 980087FZN, 980087R, 980087RGS |
| BREMBO | 08.A446.10, 08.A446.11, 25910 |
| Brembo | 08.A446.1X |
| CENTRIC | 120.51012, 120.51012CRY, 121.51012, 125.51012, 126.51012SL, 126.51012SR, 127.51012L, 127.51012R, 227.51012L, 227.51012R, 320.51012, 321.51012 |
| Casting Numbers | 211445-C, 326022 |
| Centric Parts | 120.51012, 120.51012CRY, 121.51012, 125.51012, 126.51012SL, 126.51012SR, 127.51012L, 127.51012R, 227.51012L, 227.51012R, 320.51012, 321.51012 |
| DURA CORP | BR31336, BR3133602 |
| DuraGo | BR31336, BR3133602, BR31336-02 |
| KIA | 584113A300 |
| MIGHTY DISTRIBUTING SYSTEM | 31336 |
| MONROE BRAKES | BD126201 |
| NAPA BRAKES | SDK6141 |
| NEWTEK AUTOMOTIVE | 31336 |
| Newtek Automotive USA | 31336 |
| Omnicraft | QBRR176 |
| PILENGA | 5794 |
| POWERSTOP | JBR958EVC |
| PROMAX | 14-31336, 20-31336 |
| Parts Master | 126201 |
| QUALIS | 31336 |
| QUALITY BRAND | Q232 |
| TRW | 4287 |
| TopNotch | TN980087GEO |
| UAP | 2031336, 31336 |
| Ultra Brake | HY-393 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X51555 |
| WABCO | PS126201 |
| WABCO - Archived | PS126201 |
| WAGNER BRAKE | BD126201, BD126201E |
| WINHERE | 661600 |
| WORLDPAC | 1407-78844, 1427-731839 |
RAYBESTOS 980087FZN Fits Vehicles
- Kia Sportage (2005-2016)
- Hyundai Tucson (2005-2015)
- Hyundai Santa Fe (2001-2006)
