RAYBESTOS 780690FZN Raybestos Element3 Coated Brake Rotor

★★★★★ (0)

$178.17

MSRP Pricing shown.

Out of Stock

We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.

We may have similar parts for sale. Search Alternatives >

RAYBESTOS 780690FZN Part Description

Manufacturer

RAYBESTOS

Product Description

Raybestos Element3 Coated Brake Rotor

Application Summary

2020-2012,2010-2007 Dodge Charger Front, 2020-2008 Dodge Challenger Front, 2014-2012,2010-2008 Chrysler 300 Front, 2008 Dodge Magnum Front

Features & Benefits

  • Grey Fusion 4.0(R) Coating
  • Grey Fusion 4.0® Coating
  • Grey Fusion 4.0(R) coating provides optimal corrosion resistance and faster brake jobs.
  • Grey Fusion 4.0® coating provides optimal corrosion resistance and faster brake jobs.
  • RPT(R) Rust Prevention Technology
  • RPT® Rust Prevention Technology
  • RPT(R) Rust Prevention Technology for long lasting rust prevention.
  • RPT® Rust Prevention Technology for long lasting rust prevention.
  • Cooling Vanes
  • Cooling vanes are coated to ensure vanes remain clear of rust and corrosion for optimal airflow and cooling.
  • OE Matched
  • OE Matched precision and performance.
  • Non-Directional Finish
  • A non-directional ground finish provides a product that is ready to install right out of the box.

RAYBESTOS 780690FZN Specifications

Product Attributes

ABS Tone Ring IncludedNo
Center Hole Diameter2.857 IN
Center Hole Diameter72.55 MM
ConstructionFull Cast
Conventional Or Drum-In-Hat Type RotorConventional
Discard Thickness1.181 IN
Discard Thickness30 MM
Harmonize Code8708.30.5030
Inside Diameter9.289 IN
Inside Diameter235.95 MM
Mounting Bolt Hole Circle Diameter4.528 IN
Mounting Bolt Hole Circle Diameter115 MM
Mounting Bolt Hole Diameter0.655 IN
Mounting Bolt Hole Diameter16.65 MM
Nominal Thickness1.261 IN
Nominal Thickness32.05 MM
Outside Diameter14.173 IN
Outside Diameter360 MM
Overall Height2.283 IN
Overall Height58 MM
Salability RestrictionsNo
Solid Or Vented Type RotorVented
UNSPSC Code25171715

Additional Information

Country of Origin (Primary)CN
Canadian Harmonizing Tariff Code8708309990
Harmonized Tariff Code (HTS)8708305030
UPC00887213145229

RAYBESTOS 780690FZN Cross References

BrandPart Number
ADVANCE AUTO PARTSYH145733P
AUTOZONE43149, 43149DG
BOSCH16010195
BRAKEBEST16010195, 780690, 780690FZN, 780690R, 780690RGS
CENTRIC121.63063, 125.63063, 125.63063CRY, 126.63063, 126.63063CRY, 226.63063, 320.63063F
CHRYSLER05290537AB, 05290537AC, 05290537AD, 5290537AB, 5290537ac, 5290537AD
Centric Parts121.63063, 125.63063, 125.63063CRY, 126.63063, 126.63063CRY, 226.63063, 320.63063F, 126.63063CSL, 126.63063CSR, 126.63063SL, 126.63063SR
Chrysler5290537AC
DURA CORPBR53053, BR900426
DuraGo900426, BR900426, BR900426-01
NEWTEK AUTOMOTIVE53053
Newtek Automotive USA53053
PROMAX14-53053
Qualis43149
TopNotchTN780690GEO
WABCOPS126421
WABCO - ArchivedPS126421
WAGNER BRAKEBD126421
WORLDPAC1407-335237, 1427-731900

RAYBESTOS 780690FZN Fits Vehicles

  • Chrysler 300 (2008-2010, 2012-2014)
  • Dodge Challenger (2008-2020)
  • Dodge Charger (2007-2010, 2012-2020)
  • Dodge Magnum (2008)
