DELPHI AF10309 Mass Air Flow Sensor

★★★★★ (0)

MSRP: $231.52

$178.49

Save $53.03

Limited availability at this price!

In Stock

Get as soon as Tuesday, Nov 24
30-day Return Policy On eligible items Details
Free Ground shipping on orders over $499 details
Orders placed over the weekend will be processed the next business day.

DELPHI AF10309 Part Description

Manufacturer

DELPHI

Product Description

Mass Air Flow Sensor

Features & Benefits

  • Delphi mass air flow sensors are the global benchmark for accuracy and signal noise
  • Delphi mass air flow sensors feature high quality sensing elements for outstanding performance over a wide range of ambient temperatures
  • Delphi is a manufacturer of OE mass air flow sensors since their first use over 30 years ago
  • All parts are calibrated and tested to match the OE part
  • Probe solution offered wherever possible to reduce repair time by eliminating the need to replace the flow tube
  • Delphi OE technology validated to match the vehicle applications

DELPHI AF10309 Specifications

Product Attributes

Item GradePremium
Package ContentsMass Air Flow Sensor - Probe Only
ColorBlack and Silver
Housing IncludedNo
Terminal TypeBlade
Mounting Hardware IncludedNo
Universal Or Specific FitSpecific
Grade TypeStandard Replacement
Connector Quantity1
Connector ShapeRectangle
Mounting Hole Quantity2
Terminal Quantity6
Connector GenderFemale
Terminal GenderMale
Wiring Harness IncludedNo
Mounting TypeBolt-On
Mounting Bracket IncludedNo
Sensor Casing Length83 MM
Sensor Casing Width49 MM
Voltage12.0 2H
Gasket Or Seal IncludedYes
Bolt Hole Center To Bolt Hole Center62.70 MM
Mounting Hole Diameter4.5 MM
Seal Outside Diameter28 mm
Seal Quantity1
Sensor Casing Length3.2 IN
Sensor Casing Width1.9 IN
Bolt Hole Center To Bolt Hole Center2.40 IN
Mounting Hole Diameter0.1 IN
Seal Outside Diameter1.1 IN
Intake Air Temperature (IAT) IncludedYes

Additional Information

Warranty Distance UOMDH
Warranty Distance12000
Harmonized Tariff Code (Schedule B)9026800000
Warranty Time UOMMO
Warranty Time12
Country of Origin (Primary)CN
Harmonized Tariff Code (HTS)9026802000
UPC00689604240311
VMRS Code045021019
UNSPSC41111931

DELPHI AF10309 Cross References

BrandPart Number
BWD221084M, MA1005
Beck/Arnley158-1256
Blue Streak Electronics NewMF21084N
CARDONE Reman74-50084
CarquestMQ6275
Dorman917-818, 917-920
HITACHIMAF0027
Hitachi AutomotiveAFH70-21R, MAF0027
MazdaGY01-13-215, GY01-13-215R00
N/A245-1105, MAS0118, 245-2105
NAPA Reman ComputersXTP450084
NGK SPARK PLUGSMG0086
NTKMG0086
RichporterMA246
Spectra PremiumMA246
Standard Motor ProductsMF21084
WAIMAF10127

DELPHI AF10309 Fits Vehicles

  • Mazda MPV (2000-2006)
