CEQUENT ELECTRICAL 182804 - Bulldog - SWQ 180 DL-BC-SR w/Crank (015181) Attached
- Part Number
- 182804
- Manufacturer
- CEQUENT ELECTRICAL
- Description
-
Bulldog - SWQ 180 DL-BC-SR w/Crank (015181) Attached
details
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
CEQUENT ELECTRICAL part description
California Proposition 65 Warning
California Proposition 65 Warning
WARNING: This product can expose you to chemical which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov. (Read more)
Strong, durable, and sturdy, the BULLDOG 12,000 lbs. support capacity square jack is the BIG reason why BULLDOG has carried the load in agricultural, construction, heavy-duty utility, and horse/livestock trailer industries since 1923. All BULLDOG 4" square jacks are rated for 12,000 lbs. support capacity and 10,000 lbs. lift capacity. The strength of the product, plus the wide variety of styles, makes this jack the best choice in its product class.
- 4" square tubing, 7-gauge superior alloy steel
- Painted outer tube, and drop leg
- Drop leg option with 5 positioning holes
- Easy-access gear box with grease fitting for routine maintenance
- Spring return drop leg or non-spring return drop leg
- 12.5" screw travel, 13.5" of additional adjustment with drop leg
- Front facing drop leg plunger pin or side facing drop leg plunger pin
- Painted (with or without labels) or powder paint optional
- Sidewind models - 1:1.5 gear ratio
Technical Specifications
| Brand: | Bulldog |
| Part Number: | 182804 |
| Warranty: | Limited 5 Year Warranty |
| UPC: | 086693828046 |
| Dimensions: | 24" L x 9" W x 50" H |
| Weight: | 61 lbs. |
