MUNCIE POWER PRODUCTS part description

The CS24 Series Power Take-Off is a Clutch Shift PTO designed for Allison World® and Caterpillar automatic transmissions. The CS-24 Series PTO is engaged by means of a solenoid activated, wet clutch pack. The engagement solenoid is built into the PTO and installation is simplified by the requirement of only one hose connection. A remote mounted solenoid option is available for a more compact installation.

  • Four remote mount output shafts in both keyed and flange types: Versatility for remote pump drives
  • S.A.E. "A", "B", "BB", and DIN 5462 direct mount pump options: Fits most popular pumps
  • Rotatable direct mount flanges: Allows pump to be positioned for maximum clearance
  • Compatible with PTO Shaft Extensions for Allison transmissions: Moves the pump mount to the rear of the transmission for large pump clearance
  • Patented Muncie drag brake: Prevents shaft rotation in "OFF" mode
  • Standard pressure lubrication: No extra cost
  • Two assembly arrangements: Allows the PTO to be mounted shaft high or low on either side of the transmission

Muncie Power Products® has established itself as a leading manufacturer of power take-offs, fluid power products, and hose and fittings. With 85 years of industry experience in providing high-quality products in the work truck industry, this company has proved that success is achieved through hard work, dedication, commitment, and innovation. From a humble distributor of automotive replacement parts in 1935, Muncie Power Products has grown into a large manufacturing company that primarily operates in its headquarters in Muncie, Indiana. It also maintains eight other facilities across the United States and serves customers through its global distribution network. Muncie Power Products is a proud member of the multinational Interpump Group, the largest manufacturer of power take-offs worldwide.
