(888) 312-8812 Login SignupFLEETGUARD LF3363 Lube Filter, Spin-On
$7899
Limited availability at this price!
In Stock
Get as soon as Tuesday, Oct 13
FLEETGUARD LF3363 Part Description
Manufacturer
Features & Benefits
- Packs extra pleated area into a compact size
- Diameter aligns with the engine's spin-on mounting point
- Extends available capacity by spreading contamination across media
- Dirt-holding capacity lasts further into the service interval
Fleetguard Engine Oil Filter
Pleated media construction inside the Fleetguard Engine Oil Filter folds a substantial filtration surface into a compact size, packing more area than a flat disc of the same diameter could offer. That expanded surface area spreads contamination across more total media instead of concentrating wear on one small section, extending usable capacity before restriction becomes significant. The Fleetguard LF3363 is sized to the canister diameter the spin-on filter head this engine uses accepts. More available media at the same canister size means the filter reaches its dirt-holding limit later in the service interval.
FLEETGUARD LF3363 Specifications
Product Attributes
| Capacity Test Specification | SAE J1858 IN |
| Gasket Inside Diameter | 3.8929056 IN |
| Gasket Outside Diameter | 4.3598338 IN |
| Height | 11.296856494 in |
| Hydrostatic Burst Minimum | 246.49999999999997 IN |
| Largest Outside Diameter | 4.7350299 IN |
| Media Type | StrataPore IN |
| Pressure Valve | No IN |
| Primary Particle Efficiency | 24.6 micron (c) @ 99% IN |
| Rated Flow | 39.8942 IN |
| Thread Size | 1 1/2-12 UNF 2B IN |
FLEETGUARD LF3363 Cross References
| Brand | Part Number |
|---|---|
| FGLF3363, F67Z14A664GA | |
| BALDWIN | B96-MPG |
| Baldwin | B96HPG, B96MPG, B96SS |
| Big A | 92812, 92873 |
| CARQUEST | 85812, 85873 |
| Cummins | 3312682, 3313305 |
| Donaldson | P166174, P167670 |
| FRAM | HPH3612, HPH3612FP |
| GMC | 25013192 |
| Hastings | LF432XS |
| John Deere | RE21058 |
| Kohler | 279260 |
| Komatsu | BF0829 |
| LUBER-FINER | LFH5014, LFP670HE, LFP670XL |
| N/A | LFP670, 9455081020, ELF7670, 15267513, EFL141, FP432, PER116, 172010002, 901116, KFP670, 4301181, QS3375, 24870, 2005, G051811, B7396, 35357243, FT050510, 85671, 148633-35400, 4085913, W1184, 27695, 1055914M3, PL3325, 31701670, 3I0737, 8779663, AZL135, 9350, 1220755, C3313279, 76844073, 1212622H1, 4134896, 4396645, 1930741, 3A11539, NL307, PL670, Y02926604, 25010042, H240W, 5000808716, 31133, 3754001101, 12000200, 1055914M1, 700703331, 5602720, 3A15999, OC483, 29214175, 86546625, 945197, 1046Z315, FH503V, PF892, 1202427002170, S1350553, E2750505, LS845, C5715, 991213279, 330560066, 1216400521, 12187, PS270, 2340900, WGL670, 2288131, KW670, PB670, 9414100607, 1670, PF893, GP53, SFO2670, SO3325, 31843001, Z183, A222100000614, VJ8003, B96MPG, ABP3001582, 905575, T081074, ABPN10GLF670, FT5098 |
| NAPA | 1812, 1873 |
| Pall | 1322981, PMX467010, PMX491110, PXT491110 |
| Terex | 2418694 |
| WIX FILTERS | 51970XE |
| Wix | 51812, 51873 |
