CARTER FUEL PUMPS P76504M Part Description
Manufacturer
Product Description
Fuel Pump Module Assembly
Features & Benefits
- Carter Electric Fuel Pumps and Electric Fuel Pump Assemblies are made with all new materials under rigorous quality controlled manufacturing and testing procedures.
- Quality Carter Electric Fuel Pumps and Fuel Pump Assemblies deliver optimum performance while providing long life.
- Most applications include the necessary accessories such as tank seals, patented high-gradient density strainers and wiring harnesses.
- Fuel sensor design provides resistance to corrosive fuel blends and additives.
CARTER FUEL PUMPS P76504M Specifications
Product Attributes
| Terminal Type | Pressure Contact |
| Mounting Hardware Included | No |
| Universal Or Specific Fit | Specific |
| Grade Type | Regular |
| Connector Shape | Oval |
| Gasket Or Seal Included | Yes |
| Connector Gender | Female |
| Inlet Type | Strainer |
| Outlet Type | Quick Connect |
| Fuel Filter Included | No |
| Inlet Fitting Thread Size | 3/8 IN |
| Minimum Pressure | 51.0 PS |
| Wire Harness Included | No |
| Minimum Flow Rating | 23 GPH |
| Pump Type | Electric |
| 65000 | No Proposition 65 warning is required with this product. |
| Average Current Draw | 10.0 68 |
| Average Flow Rating | N/A |
| Connector Color | Black |
| Connector Quantity | 1 |
| Fuel Sending Unit Included | Yes |
| Fuel Tank Pressure Sensor Included | No |
| Fuel Type | N/A |
| Gasket Or Seal Material | Rubber |
| Height | 236 MM |
| Height | 9.29 IN |
| Housing Length | N/A |
| Housing Material | Aluminium |
| Housing Width | N/A |
| In Tank or External | In Tank |
| Inlet Fitting Thread Size | 3/8 |
| Inlet Outside Diameter | N/A |
| Inlet Quantity | N/A |
| Internal or External | External |
| Lock Ring Included | No |
| Maximum Pressure | N/A |
| Minimum Pressure | 43.5 PSI |
| Outlet Fitting Thread Size | N/A |
| Outlet Outside Diameter | 9.49 MM |
| Outlet Outside Diameter | 0.37 IN |
| Outlet Quantity | 1 |
| Outlet Thread Diameter | N/A |
Additional Information
| Country of Origin (Primary) | CN |
| Country of Origin 2 | MX |
| EAR99 | |
| Harmonized Tariff Code (HTS) | 8413309030 |
| Warranty Special | Limited Lifetime Warranty |
| Warranty Special UOM | TX |
| UPC | 00019826101174 |
| VMRS Code | 044003258 |
| UNSPSC | 40151532 |
CARTER FUEL PUMPS P76504M Cross References
| Brand | Part Number |
|---|---|
| 1-800-Radiator | 2920270 |
| AIRTEX | E7185M |
| AUTOBEST | F3196A |
| Airtex Fuel Pumps | E7185M |
| Bosch Fuel Pumps | 69969 |
| Carquest Premium Fuel Pumps | M2520918 |
| Chrysler | 5114 302AA, 5114 302AB, RL114302AA |
| DELPHI | FE0300, FG1351 |
| Delphi Fuel Pumps | FG1351 |
| GMB | 520-2115 |
| N/A | E7185M, 2920270, 5114 302AA, 5114 302AB, 520-2115, 69969, A30278, C0479M, FG1351, M2520918, RL114302AA, SP7018M |
| NAPA Fuel Pumps | C0479M |
| Precision Fuel | A30278 |
| Spectra Premium | SP7018M |
| TYC | 150169 |
| TruGrade | B13112464TG |
CARTER FUEL PUMPS P76504M Fits Vehicles
- Dodge Dakota (2004)
