(888) 312-8812 Login SignupRAYBESTOS 581034 Raybestos Specialty - Street Performance Brake Rotor
$10399
Limited availability at this price!
In Stock
Get it by Friday, Aug 14
RAYBESTOS 581034 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Application Summary
2020-2013 Chevrolet Trax Front, 2014-2013 Chevrolet Sonic Front, 2019 Buick Encore Front
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 581034 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.362 IN |
| Center Hole Diameter | 60 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.906 IN |
| Discard Thickness | 23 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 7.083 IN |
| Inside Diameter | 179.9 MM |
| Mounting Bolt Hole Circle Diameter | 4.124 IN |
| Mounting Bolt Hole Circle Diameter | 104.75 MM |
| Mounting Bolt Hole Diameter | 0.561 IN |
| Mounting Bolt Hole Diameter | 14.25 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.024 IN |
| Nominal Thickness | 26 MM |
| Outside Diameter | 11.811 IN |
| Outside Diameter | 300 MM |
| Overall Height | 1.791 IN |
| Overall Height | 45.5 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213157390 |
RAYBESTOS 581034 Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | YH527280P |
| AUTOXTRA | AX901406 |
| AutoZone | 72027DL |
| Autoxtra | AX901406P |
| BRAKEBEST | 581034, 581034FZN, 581034R |
| CENTRIC | 120.62148, 121.62148, 320.62148, 120.62142 |
| Centric Parts | 120.62148, 121.62148, 320.62148 |
| DURA CORP | BR901406 |
| DuraGo | BR901406 |
| Dynamic Friction Company | 600-45020 |
| GM | 13502059, 13502064, 23118342 |
| General Motors | 13502059, 13502064, 23118342 |
| NAPA BRAKES | SDK6786 |
| NEWTEK AUTOMOTIVE | R1406 |
| Newtek Automotive USA | R1406 |
| Qualis | 41318 |
| TopNotch | TN581034GEO |
| WORLDPAC | 1407-527280, 1427-712953 |
| Wagner Brake | BD180859E |
RAYBESTOS 581034 Fits Vehicles
- Buick Encore (2019)
- Chevrolet Trax (2013-2020)
- Chevrolet Sonic (2013-2014)
RAYBESTOS 581034 Customer Reviews
No reviews yet
Be the first to review this product!
RAYBESTOS 581034 Questions & Answers
No questions yet
Be the first to ask a question about this product!
