(888) 312-8812 Login SignupRAYBESTOS 781774 DISC BRK ROTOR
$19599
Limited availability at this price!
In Stock
Get it by Wednesday, Sep 2
RAYBESTOS 781774 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Application Summary
2022-2014 Dodge Charger Front
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 781774 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.858 IN |
| Center Hole Diameter | 72.6 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 1.201 IN |
| Discard Thickness | 30.5 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 9.094 IN |
| Inside Diameter | 231 MM |
| Mounting Bolt Hole Circle Diameter | 4.528 IN |
| Mounting Bolt Hole Circle Diameter | 115 MM |
| Mounting Bolt Hole Diameter | 0.657 IN |
| Mounting Bolt Hole Diameter | 16.7 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.26 IN |
| Nominal Thickness | 32 MM |
| Outside Diameter | 14.567 IN |
| Outside Diameter | 370 MM |
| Overall Height | 2.222 IN |
| Overall Height | 56.45 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213137101 |
RAYBESTOS 781774 Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | YH527284P |
| AUTOZONE | 72137, 72137DG |
| AutoZone | 72137DL, 72137P |
| Autoxtra | AX901384, AX901384P |
| BRAKEBEST | 721784RGS, 781774, 781774FZN, 781774P, 781774PER, 781774R |
| CENTRIC | 120.63086, 121.63086, 125.63086, 126.63086SL, 126.63086SR, 127.63086L, 127.63086R, 320.63086F |
| CHRYSLER | 68184337AA, 68184337AB, 68368069AA |
| Centric Parts | 120.63086, 121.63086, 126.63086SL, 126.63086SR, 127.63086L, 127.63086R, 320.63086F, 125.63086 |
| DURA CORP | BR901384 |
| DuraGo | BR901384, BR901384-02, BR901384-03 |
| Dynamic Friction Company | 900-40035 |
| MAGMA PRODUCTS | PSR143080 |
| NEOTEK | 1070121GF |
| NEWTEK AUTOMOTIVE | R1384, R712 |
| Newtek Automotive USA | R1384, R712 |
| Performance Friction | 370.057.01 |
| Qualis | 43196 |
| WAGNER | BD180395E |
| WAGNER BRAKE | BD180660 |
| WORLDPAC | 1407-527284, 1427-613671 |
| Wagner Brake | BD180660E |
| Winhere | 6621784 |
RAYBESTOS 781774 Fits Vehicles
- Dodge Challenger (2017-2022)
- Chrysler 300 (2014-2021)
- Dodge Charger (2014-2023)
