DELPHI GN10494 Ignition Coil

★★★★★ (0)

MSRP: $83.55

$63.49

Save $20.06

Limited availability at this price!

In Stock

Get as soon as Friday, Nov 20
30-day Return Policy On eligible items Details
Free Ground shipping on orders over $499 details

DELPHI GN10494 Part Description

Manufacturer

DELPHI

Product Description

Ignition Coil

Features & Benefits

  • Delphi coils provide OE performance, durability and electromagnetic capacity level requirements
  • Delphi ignition coils are designed to insert power into spark plugs to ensure fast starts, consistent engine performance and optimized fuel efficiency
  • Delphi uses smart winding process techniques to controls wire lengths, keeping voltage the same
  • We manufacture our ignition coils with a high quality wire coating that resists imperfections that lead to failure

DELPHI GN10494 Specifications

Product Attributes

Package ContentsIgnition Coil
Ignition TypeElectronic
Coil TypeCoil On Plug Ignition
Coil Wire IncludedNo
Oil FilledNo
Requires External ResistorNo
Terminal TypeBlade
Mounting Hardware IncludedYes
Wire Quantity0
Grade TypeStandard Replacement
Mount Type1 Mounting Hole with 1 Bolt / Screw attached
Mounting Hole Quantity1
Terminal Quantity3
Connector GenderFemale
Terminal GenderMale
Voltage12.0 2H
Length2.331 IN
Height6.118 IN
Length59.2 MM
Height155.4 MM
ColorBlack & Silver
Connector Quantity1
Connector ShapeElliptical

Additional Information

Warranty Distance UOMDH
Warranty Distance36000
Harmonized Tariff Code (Schedule B)8511300080
Warranty Time UOMMO
Warranty Time36
Country of Origin (Primary)CN
Harmonized Tariff Code (HTS)8511300080
UPC00689604230329
VMRS Code033003001
UNSPSC26101769

DELPHI GN10494 Cross References

BrandPart Number
ACDelcoD515C
Airtex5C1612
BWDE1069
Beck/Arnley178-8435
BorgWarnerE1069
Carquest52-1853, 26C1033
DENSO673-7300, 673-7303
DENSO Auto Parts673-7300
DuralastC1555
EchlinIC649
General Motors12590990, 12618542, 12632479
HITACHIIGC0173
HOLSTEIN2IGC0137
IMCCLS1226
MasterPro Ignition2-50228
N/A3340078J03, 3340078J00, 3340078J01, 921X2109
NAPA Mileage PlusIC649SB
NGK SPARK PLUGSU5130, 49018, 49419, U5130-6
Original Engine Management50228
PRENCO36-8122
RichporterC-761
STANDARD IGNITIONUF569
Saab12632479, 12618542, 12590990
Spectra PremiumC-761
Standard Motor ProductsUF-569
Suzuki33400-78J00, 33400-78J01, 33400-78J02, 33400-78J03
Walker Products921-2109
WellsC1555

DELPHI GN10494 Fits Vehicles

  • Buick Enclave (2008, 2010-2024)
  • Buick LaCrosse (2010-2016)
  • Cadillac ATS (2013-2017)
  • Cadillac CT4 (2022-2024)
  • Cadillac CTS (2008-2017)
  • Cadillac SRX (2007-2016)
  • Cadillac STS (2010-2011)
  • Cadillac XTS (2013-2019)
  • Chevrolet Camaro (2010-2015)
  • Chevrolet Caprice (2012-2017)
  • Chevrolet Captiva Sport (2012)
  • Chevrolet Colorado (2015-2016)
  • Chevrolet Equinox (2008-2017)
  • Chevrolet Impala (2012-2020)
  • Chevrolet Impala Limited (2014-2016)
  • Chevrolet Malibu (2008-2012)
  • Chevrolet Traverse (2010-2022)
  • GMC Acadia (2007-2008, 2010-2016)
  • GMC Acadia Limited (2017)
  • GMC Canyon (2015-2016)
  • GMC Terrain (2010-2017)
  • Pontiac G6 (2007-2009)
  • Pontiac G8 (2008-2009)
  • Pontiac Torrent (2008-2009)
  • Saab 9-5 (2010-2011)
  • Saturn Aura (2007-2009)
  • Saturn Outlook (2007-2008, 2010)
  • Saturn Vue (2008-2010)
  • Suzuki Grand Vitara (2009-2010)
  • Suzuki XL-7 (2007-2009)
