(888) 312-8812 Login SignupDELPHI AF10162 Mass Air Flow Sensor
MSRP: $225.80
$16999
Save $55.81
Limited availability at this price!
In Stock
Get it by Thursday, Feb 5
DELPHI AF10162 Part Description
Manufacturer
Product Description
Mass Air Flow Sensor
Features & Benefits
- Delphi mass air flow sensors are the global benchmark for accuracy and signal noise
- Delphi mass air flow sensors feature high quality sensing elements for outstanding performance over a wide range of ambient temperatures
- Delphi is a manufacturer of OE mass air flow sensors since their first use over 30 years ago
- All parts are calibrated and tested to match the OE part
- Probe solution offered wherever possible to reduce repair time by eliminating the need to replace the flow tube
- Delphi OE technology validated to match the vehicle applications
DELPHI AF10162 Specifications
Product Attributes
| Item Grade | Premium |
| Package Contents | Mass Air Flow Sensor - Probe Only |
| Color | Black |
| Housing Included | No |
| Terminal Type | Blade |
| Mounting Hardware Included | No |
| Universal Or Specific Fit | Specific |
| Grade Type | Standard Replacement |
| Connector Quantity | 1 |
| Connector Shape | Rectangle |
| Mounting Hole Quantity | 2 |
| Terminal Quantity | 5 |
| Connector Gender | Female |
| Terminal Gender | Male |
| Wiring Harness Included | No |
| Mounting Type | Bolt-On |
| Mounting Bracket Included | No |
| Sensor Casing Length | 60 MM |
| Sensor Casing Width | 37.6 MM |
| Voltage | 12.0 2H |
| Gasket Or Seal Included | Yes |
| Bolt Hole Center To Bolt Hole Center | 47.00 MM |
| Mounting Hole Diameter | 5.6 MM |
| Seal Outside Diameter | 34.8 mm |
| Seal Quantity | 1 |
| Sensor Casing Length | 2.3 IN |
| Sensor Casing Width | 1.4 IN |
| Bolt Hole Center To Bolt Hole Center | 1.80 IN |
| Mounting Hole Diameter | 0.2 IN |
| Seal Outside Diameter | 1.3 IN |
| Intake Air Temperature (IAT) Included | Yes |
Additional Information
| Harmonized Tariff Code (HTS) | 9026802000 |
| Warranty Distance UOM | DH |
| Warranty Distance | 12000 |
| Harmonized Tariff Code (Schedule B) | 9026800000 |
| Warranty Time UOM | MO |
| Warranty Time | 12 |
| Country of Origin (Primary) | CN |
| UPC | 00689604231197 |
| VMRS Code | 045021019 |
| UNSPSC | 41111931 |
DELPHI AF10162 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | 2133581 |
| Airtex | 5S2936 |
| BWD | 221045M, 221163, MA1038, MA1103 |
| Beck/Arnley | 158-0689, 158-0691, 158-0695 |
| Bosch | 0280218090, 0280218106, 0280218111 |
| CARDONE New | 86-10103 |
| CARDONE Reman | 74-10089, 74-10092, 74-10103 |
| Carquest | MQ6239, MQ7379 |
| Dorman | 917-987 |
| Duralast | DL-3054, DL-6056, DL-6057 |
| GLOBAL PARTS DISTRIBUTORS | 1813127 |
| Hyundai | 28100-39400, 28164-38200, 28164-38210 |
| Kia | 28100-2Y100, 28100-39400, 28100-39450, 28164-38200, 28164-38210 |
| N/A | 281002Y100, 2810039450, 2816438210, 213-3581, 245-1088, MF21390, 5S2987, 245-1092, 245-2088, 245-2092, MAS0445, MQ7232, DL-3055 |
| NAPA Reman Computers | MAF610103, XTP410089, XTP410092, XTP410103 |
| NGK SPARK PLUGS | MG0047 |
| NTK | MG0047 |
| Richporter | MA136, MA137 |
| STANDARD IGNITION | MAS0165, MAS0445, MAS0266 |
| Spectra Premium | MA136, MA137, MA289 |
| Standard Motor Products | MF21163, MF21045, MAS0165, MAS0266, MF21049 |
| VEMO | V52720019 |
| WAI | MAF10162 |
| WALKER PRODUCTS | 245-1249, 245-1088 |
| Wells | SU6198, SU6921, SU6930 |
DELPHI AF10162 Fits Vehicles
- Kia Amanti (2004-2006)
- Kia Spectra (2002-2004)
- Kia Sorento (2003-2006)
- Kia Optima (2003-2006)
- Kia Sedona (2002-2005)
- Hyundai XG350 (2002-2005)
- Hyundai Sonata (2003-2005)
- Hyundai XG300 (2001)
- Hyundai Santa Fe (2001-2006)
